Table of contents
1
Introduction ........................................................
2
Description of the product ..................................
3
Scope of delivery................................................
4
Proper use..........................................................
5
Safety instructions..............................................
6
Technical data....................................................
7
Unpacking ..........................................................
8
Before commissioning........................................
9
Operation ...........................................................
10 Working instructions...........................................
11 Cleaning and maintenance ................................
12 Storage and transport ........................................
13 Repair and ordering spare parts ........................
14 Disposal and recycling .......................................
15 Troubleshooting .................................................
16 Warranty conditions - Scheppach 20V IXES se-
ries .....................................................................
17 EU Declaration of Conformity.............................
18 Exploded view .................................................... 292
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Wear hearing protection. Excessive noise
can result in a loss of hearing.
Do not expose the product to rain.
Guaranteed sound power level of the prod-
uct.
Lithium-ion battery
The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
1
Introduction
17
Manufacturer:
17
Scheppach GmbH
18
Günzburger Straße 69
18
D-89335 Ichenhausen
18
Dear Customer
21
We hope your new product brings you much enjoyment
and success.
21
Note:
21
In accordance with the applicable product liability laws,
22
the manufacturer of this product assumes no liability for
23
damage to the product or caused by the product arising
from:
23
• Improper handling
24
• Non-compliance with the operating manual
24
• Repairs carried out by third parties, unauthorised spe-
24
cialists
25
• Installing and replacing non-original spare parts
• Improper use
26
• Failures of the electrical system in the event of the
27
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2
Description of the product
1.
Transport handle
2.
Battery mount
3.
On/off switch
4.
Manometer (vessel pressure)
5.
Manometer (operating pressure)
6.
Quick coupling
7.
Pressure vessel
8.
Drain plug (condensation water)
9.
Pressure regulator (operating pressure)
10.
Safety valve
11.
"Overload protection" button
12.
Tyre pressure gauge
12a.
Manometer
13.
Trigger
14.
Compressed air hose (quick coupling connection)
15.
Compressed air hose (valve adapter)
15a.
Valve adapter
16.
Battery*
16a.
Release button (battery)
www.scheppach.com
GB | 17
