6 Technical data
Rated voltage
Pressure vessel volume
Maximum operating pressure
Suction capability
Weight (without battery)
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration levels have been determined in
accordance with ISO 3744 and EN ISO 2151:2008.
Sound pressure level L
pA
Measurement uncertainty K
Guaranteed sound power level L
Sound power level L
wA
Measurement uncertainty K
Vibration parameters (hand/arm vibration)
Vibration a
h
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the electric tool is used, and in par-
ticular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
40 V (2x20V)
approx. 8 bar
approx. 130 l/min
10 kg
74.2 dB
1.97 dB
pA
96 dB
wA
94.2 dB
1.97 dB
wA
≤ 2,5 m/s2
www.scheppach.com
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
6 l
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Before commissioning
Tool required:
• Open-ended spanner, size 14 mm*
* = may not be included in the scope of delivery!
8.1 Connect the compressed air hose
(14) to the product (Fig. 3)
1. Insert the compressed air hose (14) into the quick
coupling (6) to connect it to the product.
8.2 Select the attachment (15/17) for
the tyre pressure gauge (12)
(Figs. 3, 4)
Select the appropriate attachment (15/17) for the work to
be carried out:
• Compressed air hose (15) with valve adapter
(15a):
The compressed air hose with valve adapter offers
you the option of flexibly using a variety of adapters
for a wide range of applications.
• Extension adapter (17):
The extension adapter is screwed directly onto the
tyre pressure gauge. It is an additional extension that
makes it easier to access hard-to-reach areas.
8.3 Mount the compressed air hose
(14) or extension adapter (17) on
the tyre inflation pressure gauge
(12) (Figs. 3, 4)
1. Fit the compressed air hose (15) or the extension
adapter (17) on the tyre inflation pressure gauge (12).
Use an open-ended spanner SW 14 mm.
8.4 Connect the tyre pressure gauge
(12) to the compressed air hose
(15) (Fig. 3)
1. Connect the tyre pressure gauge (12) to the com-
pressed air hose (15) by inserting it into the quick cou-
pling of the compressed air hose (15).
