02 - Rating plate
Duo
DazeTechnology S.r.l.
Via Aldo Moro,2C
24030 Almenno S.B. - Italia
For use with EV
PN: xxxxxxxxxx
SN: xxxxxxxxxxx
TYPE: xxxxxxxxxx
400/230Vac
32Amax
@25°C
IP56
1P/3P+N+PE 50Hz
QR SN
03 - Screen interface
1. Numeric interface:
Charging power indicator (kW) or delivered energy (kWh)
2. Light icons
03.1 - LED bars
There are 2 LEDs on the sides, each indicating the status of the
corresponding charging socket
Led Duo status
1
Stand-by
Charging
2
Waiting for vehicle
3
4
Charging suspended
5 Cooling down
6 Software update
7 Charging locked
+
8 Out of service
9
Vehicle connected and charging
- Vehicle connected but not charging
- Vehicle fully charged
Charging suspended due to excessive
Installing the software update;
follow instructions on the App
Waiting for charging activation
Not communicating with the OCPP
server or the master charger
Potential malfunction; check the
Error
error code on the display and refer
The Duo model can be identified by checking
the data plate, located inside the device (as
shown in the image).
In case of a service request for the product,
please provide the serial number (SN) of the
charger.
Description
Ready to charge
- Insufficient power
- Suspended by user
internal temperature
via App or RFID
to chapter 10
1
2
Load Balancing
Ready to charge
Vehicle connected and charging
- Vehicle connected but not charging
- Vehicle fully charged
- Calculating available power
- Suspended by user
- Vehicle excluded from power allocation,
possibly because it is fully charged
Charging suspended due to excessive
internal temperature
Installing the software update;
follow instructions on the App
Waiting for charging activation
via App or RFID
Not communicating with the OCPP
server or the master charger
Potential malfunction; check the
error code on the display and refer
to chapter 10
