DAZE Duo T Installationsanleitung Seite 6

EN
Security
Key lock
Intrusion monitoring
Temperature monitoring
Fire safety
DC leakage current detection (RDC-DD)
Overvoltage category
Differential magnetothermal protection (RCBO)
1. Nominal current
2. Differential protection type
3. Tripping curve
4. Differential leakage current
5. IGA interruption power
6. Reference standard
Environmental resistance
IP protection rating
IK protection rating
Operating environment
Operating temperature
Storage temperature
Maximum installation altitude
Installation
Configuration of maximum nominal current
Charger and accessories configuration
Anchoring
Cable routing
Certifications
Certification
International reference standard
6.
Single-phase version
Integrated with overheating protection
Integrated, one protection for each connection point
40 A
Type A
C
30 mA
6 kA
EN 61009-1, EN 61009-2-1
2000 m (above sea level)
Wall-mounted or on SD01 ground support
Flush-mounted or surface-mounted with cable section from 6mm² to 25mm²
IEC EN 61851-1, IEC EN 61851-21, IEC EN 62196-2
Three-phase version
Yes
Via optical sensor
UL94 V-0
Integrated, 6 mA DC
OVC III
Type A
30 mA
EN 61009-1, EN 61009-2-1
IP55
IK10
Indoor and outdoor
From -30 ºC to +55 ºC
From -30 ºC to +60 ºC
Via dip switch
Via App
CE
40 A
C
10 kA
