The attachment clicks into place.
Removing the nozzle
1. Pull and hold the quick connector
ring (21) on the lance (4).
2. Pull the attachment off the lance
(4).
3. Release the quick connector ring
(21).
4. Remove the lance (4) from the
trigger gun (1) (Bayonet locking
device: push, turn and pull).
Mounting the surface cleaner (24)
1. Remove the lance (4) from the
trigger gun (1) (Bayonet locking
device: push, turn and pull).
2. Optional: Fit the extension tube (7)
on the pivotable connection (26) of
the surface cleaner (Bayonet lock-
ing device: plug and turn).
3. Fit the extension tube (the pivot-
able connection of the surface
cleaner) on the trigger gun (1).
4. Secure the pivotable connection
and the extension tube with the
coupling nuts. The Bayonet lock-
ing devices must not be able to be
opened.
Removing the surface cleaner (24)
1. Loosen the coupling nuts on the
pivotable connection (26) and the
extension tube (7).
2. Remove the extension tube (the
connection of the surface clean-
er) from the trigger gun (1) (Bayon-
et locking device: push, turn and
pull).
3. Remove the extension tube from
the pivotable connection (26) (Bay-
onet locking device: push, turn
and pull).
40
Operation
Cleaning using cleaning
agent
Requirements for the cleaning
agent
• This device has been designed to
be used with a neutral cleaning
agent based on biodegradable an-
ionic surfactants.
• Use of other cleaning agents or
chemicals can negatively impact
the safety of the device and can
cause damage. Such damage to
the device is not covered by the
warranty.
• You can buy cleaning agents from
our online shop.
Requirements
• The cleaning agent tank is filled
with cleaning agent.
• The rotatable pressure setting (20)
on the trigger gun (1) is at the po-
sition high pressure for walls and
foam, the LC display (15) shows
Filling and emptying the cleaning
agent tank
1. Remove the sealing cap with suc-
tion hose (12) from the cleaning
agent tank (13).
2. Pull the cleaning agent tank up
and then away from the device.
The cleaning agent tank is re-
moved and can be filled or emp-
tied.
3. Insert the cleaning agent tank in
reverse order.
4. Seal the cleaning agent tank with
the sealing cap.
5. Push the suction hose into the
cleaning agent tank until it reaches
the bottom.
.
