Parkside Performance PHDP 180 C2 Originalbetriebsanleitung Seite 30

GB MT
25 Pressure regulator (Surface clean-
er)
26 Pivotable connection (Surface
cleaner)
27 Cleaning agent
28 Water connection
29 Coupling (Water connection)
30 Filter insert
31 Holder (Trigger gun)
32 On/Off switch
33 Holder for nozzles
34 Quick connector with garden
hose adaptor
35 Alkaline battery (1,5 V; AAA/LR03)
Technical data
Pressure Washer ........PHDP 180 C2
Rated voltage U ..........230 V ∼; 50 Hz
Rated output P .......................3000 W
Length Power cord .......................5 m
Protection class .................................I
Protection type ............................IPX5
Weight .................................... 21.6 kg
Length of high-pressure hose .... 10 m
Operating pressure (p) ........... 15 MPa
Max. permissible pressure (p
................................................ 18 MPa
Max. inlet pressure (p
Max. inlet temperature (T
Rated flow rate (Q) ..... 540 l/h (9 l/min)
Max. rated flow rate (Q
.................................. 600 l/h (10 l/min)
Max. suction height ...................0.5 m
Sound pressure level (L
...............................79.8 dB; K
Sound power level (L
– Measured ..... 92.9 dB; K
– Guaranteed ............................ 98 dB
Vibration (a ) ......................≤2.50 m/s²
h
30
)
max
) ... 0.8 MPa
in;max
) ..40 °C
in;max
)
max
)
pA
=3 dB
pA
)
WA
=2.41 dB
WA
Information on the power supply
This device is intended to be oper-
ated using a mains supply network
with a system impedance Z
transfer point (house connection) of
max. (0.300 + j 0.188) Ohm. The user
must ensure that the device is only
operated using a mains supply net-
work that meets the requirements. If
necessary, local power supply com-
panies can be consulted with regards
to the system impedance.
Levels of noise and vibration were de-
termined according to the standards
and regulations in the declaration of
conformity.
The specified total vibration value and
the stated noise emission value have
been measured according to a stand-
ardised test method and can be used
to compare one power tool with an-
other. The specified total vibration
value and the stated specified noise
emission value can also be used for a
provisional assessment of the load.
WARNING! The vibration and
noise emissions may deviate from
the specified values during actual
use of the power tool, depending on
how the power tool is being used. Try
to keep the exposure to vibrations
as low as possible. An example of a
measure to reduce vibration expos-
ure is limiting the working hours. All
parts of the operating cycle have to
be considered while doing so (for ex-
ample, times when the power tool
is switched off and times when it is
switched on but running without any
load).
on the
max
