Parkside Performance PHDP 180 C2 Originalbetriebsanleitung Seite 37

is irritated. Call a doctor if
irritation persists.
After swallowing: Do
•
not force vomiting. If the
affected person is con-
scious, make sure that
they rinse their mouth
and the surrounding
areas of skin with water
for at least 15 minutes.
Consult a doctor right
away. Call a doctor right
away.
Preparation
WARNING! Risk of injury due to
unintentional start-up. Do not in-
sert the plug into the outlet until the
device is fully prepared for use.
Operating elements and
how they work
Familiarise yourself with the operating
elements before using the device for
the first time.
Trigger gun (1)
• Switch lever (17)
• Pulling the switch lever: Activ-
ates the pressure jet
• Releasing the switch lever: De-
activates the pressure jet
• Switch lever child safety lock
(18) (seen from behind)
⭠ The switch lever is locked ὑ.
⭢ You can pull the switch lever ὑ.
WARNING! Risk of injury due to
pressure jet! Lock the switch lever
every time you take a break.
• Pressure setting (20)
The trigger gun pipe can be turned
through three levels.
• ⭯ low pressure
• ⭮ high pressure
• LC display (15)
The display shows the set pressure
when the switch lever is pulled.
high pressure for walls and
foam
medium pressure for
vehicles
low pressure for sensitive
objects
Bow-type handle (2)
With the bow-type handle pulled out,
you can conveniently roll the device.
• Pulling out the handle:
Pull the bow-type handle up.
• Pulling in the handle:
Press the release (3) on the bow-
type handle and pull the bow-type
handle down.
Inserting the batteries
Insert the batteries in the battery
compartment before using the device
for the first time.
Tools required
• Phillips screwdriver (not included)
Procedure
1. Remove the screw from the bat-
tery compartment cover (16).
2. Remove the cover of the battery
compartment.
3. Insert the batteries (35) in the bat-
tery compartment. Pay attention to
the correct polarity when inserting
the batteries in the battery com-
partment.
4. Press the switch lever (17) on the
trigger gun (1).
GB MT
37
