The LC display shows the selected
pressure. If the LC display is not
displaying anything, check the dir-
ection of the batteries.
5. Insert the cover of the battery
compartment.
6. Fasten the cover of the battery
compartment using the screw.
Initial start-up
1. Water connection (28): Remove
the plug.
It is possible that water may es-
cape.
Setting up the device
1. Place the device horizontally on a
level surface.
2. Make sure that the high-pressure
hose (8) passes through the guide
for the high-pressure hose (9).
3. Insert the high-pressure hose (8)
into the high-pressure connection
on the trigger gun (1).
Establishing a water supply
You have two options to supply the
device with water:
• Household water connection
• Suctioning standing, clean water,
e.g. rain barrel
Household water connection
Requirements
• Supply hose: Garden hose with fit-
ted quick connector with garden
hose adaptor (34); ⌀ 13 mm (½");
length between 5 m and 30 m
• Minimum pump capacity: 540 l/h
(9 l/min)
• System separator
A system separator (check valve)
prevents the backflow of water and
cleaning agent into the drinking
water pipeline.
38
• According to current regulations,
a pressure washer must nev-
er be connected to the drink-
ing water network without a sys-
tem separator. A suitable sys-
tem separator must be used in
accordance with EN 12729 Type
BA.
• Water that has flowed through a
system separator is classified as
non-potable.
• System separators are available
from specialist dealers.
Procedure
1. Insert the filter insert (30) in the
water connection (28).
2. Fit the coupling (29) on the water
connection (28).
3. Attach the quick connector with
garden hose adaptor (34) to the
supply hose.
• Remove the grooved clamping
nut.
• Push the clamping nut over the
end of the hose.
• Insert the end of the hose into
the thread of the quick connect-
or with garden hose adaptor.
• Fix the quick connector with
garden hose adaptor with the
clamping nut.
• Check whether the quick con-
nector with garden hose adaptor
is fitted securely to the hose.
4. Connect the supply hose to the
water supply.
5. Bleed the supply hose: Open the
water supply until the water flows
bubble-free out of the other end of
the supply hose. Close the water
supply.
6. Connect the quick connector with
garden hose adaptor (34) on the
supply hose to the coupling (29).
