Opera Fusion IFU038A0 Installations- Und Benutzerhandbuch Seite 54

5.9 ACTIVATION OF PERMANENT KEY
If two or more sensor keys are pressed simultaneously (for example, if a pot is accidentally
placed on a key), no function will be activated. The system performs a check on the
permanent activation of the keys: if a sensor remains activated for more than 10 seconds, the
cooktop enters OFF mode, emitting an acoustic signal for 10 seconds and displaying "Er03"
until the permanent activation is recognized. As soon as the permanent activation ends, the
cooktop can return to normal operation.
5.10 OVERHEATING PROTECTION
The induction cooktop is equipped with an overheating safety device designed to protect
the electronic components. This device operates on multiple levels: when the temperature
of the cooktop reaches high levels, the two-level fan is activated first. If this is not sufficient,
the Booster function is disabled, and the device reduces the power of some cooktops or
completely turns them off. Once cooled, the cooktop returns to maximum power. If the
message E2 appears frequently during normal use and at room temperature, it may indicate
insufficient cooling, especially if the kitchen furniture does not have adequate openings. It is
important to ensure that the front of the cabinet has an opening of at least 5 mm.
5.11 COOKTOP CONTROL WITH TOUCH SENSORS
• SLIDER CURSOR
The use of the ceramic glass cooktop
is done via the touch control sensor
buttons. To activate a button, simply
lightly touch the symbol on the ceramic
glass surface. Each correct activation
is confirmed by an acoustic signal. For
simplicity, the touch control buttons will
be referred to as "buttons."
•
• WHAT TO OBSERVE DURING THE USE
OF THE ADJUSTMENT FIELDS:
Avoid resting your finger too much
on the ceramic glass surface to avoid
accidentally activating adjacent buttons
or adjustment fields.
• TOUCH LIGHTLY THE CONTROL AREA
OR SLIDE YOUR FINGER
You can lightly press the control area
with your finger to gradually change the
setting on the display (power level). By
placing your finger on the control area
and sliding it right or left, the display
setting will change progressively. The
faster the movement, the quicker the
change on the display.
54 | FUSION
WRONG
CORRECT
TOCCARE
1 2 3 4 5 6 7 8 9 P
SCORRERE
1 2 3 4 5 6 7 8 9 P
FINGER
GLASS-CERAMIC
SENSOR
FINGER
GLASS-CERAMIC
SENSOR
