Opera Fusion IFU038A0 Installations- Und Benutzerhandbuch Seite 45

(MM)
≥ 800
A
≥ 50
B
≥ 20
C
E
≥ 80
D
≥ 5
E
≥ 30
F
≥ 250
G
3.2 INSTALLATION DIMENSIONS
IFU038A0 IFU058A0 IFU078A0 IFU078B0 IFU088A0
380 580
A
510 510
B
360 560
C
480 480
D
55 55
E
6 6
F
≥ 50 ≥ 50
G
≥ 600 ≥ 600
H
3.3 INSTALLATION OF THE FOAM GASKET
Before inserting the appliance into the opening of the kitchen worktop, it is necessary to
attach the provided foam gasket to the underside of the glass.
Do not install the appliance without the foam gasket!
The gasket must be attached to the appliance by following these steps:
• Remove the protective film from the gasket.
• Attach the gasket to the underside, approximately 2-3
mm from the edge. Ensure that the gasket is applied
along its entire length without overlapping at the
corners.
• During the installation of the gasket, take care not to
let sharp objects touch the glass.
C
1
B
E
F
780 780 880
510 510 510
750 750 840
480 480 480
55 55 55
6 6 6
≥ 50 ≥ 50 ≥ 50
≥ 600 ≥ 600 ≥ 600
A
B
C
D
B
C
A F
E
D
G
H
A
INDUCTION HOB | 45
