Fuse holder with fuse link (optional)
3.8
Figure 3.10Fuseholder with fuse link
Each fuse holder is coated with a silver layer and equipped
with a spring. This creates a long-lasting contact between
the fuse link and the fuse
The fuse links with gPV fuses according to IEC 60269-
6:2010 protect the PV string cables against overcurrent.
The fuse links are equipped with silver-coated end caps for
the lowest possible contact resistance.
3.9 Surge protection according to DIN EN
50539-12
The use of the PV Next String Combiner Box as surge pro-
tection according to DIN EN 50539-12:2014 depends on
the distance between the PV generators and the inverter.
1 2
SPD
5
Figure 3.11Surge protection in the PV system
1 Mains connection
2 Main distribution
3 PV inverter
PV generator
4
5 Earthingsystem
6 Additionalearthingconnection
2690250000/05/10.2022
holder.
3 4
SPD SPD
IV
6
Outer light. Separation
ning protec- distance
tion system S20.7 1.0 m
present observed
x x
x x
x x
x x
x
x
x
x
DINEN 50539-12:Requirementsfor surge voltage arresters depending
on application
Observe the cross-sections
earth cable required in DIN EN 50539-12:2014:
Type II: At least 6 mm2 or equal to the cross-sec-
tion of the active conductor if it is greater than
6 mm2.
Type l: At least 16 mm2 or equal to the
cross-section of the active conductor if it is great-
er than 16 mm2.
3.10 Observe the LPL
Select products that meet the requirements of
the lightening protection level (LPL) at the instal-
lation site.
Please ask your building insurance company for
the applicable LPL.
10/350 ps
LPLI
l. 2375U,G27SkA
LPL II
LPL IMV 22SkA
Weidmüller
Product description
Cable In front of Behind
length the inverter PV generators
12<10 m
Type II
x
Type II
Type II
x
Type II
x
Type II
Type II
x
x
Type I Type I
x
of the functional
In2 7.5kA
IOU
the
15kA
