Settings

4

Operating the devices

The basic ZEV units must be configured prior to initial
commissioning. The device provides three buttons for these
operations:
• The MODE function key for selecting the various menus.
To acknowledge the entries made in the menus, press the
MODE button.
• The UP/DOWN button for selecting the desired values
from the various menus.
• The RESET/TEST button to exit the menus without saving
the values and to return to the previous menu.
The following Figure 22 provides an overview of all possible
settings at the basic unit.
