age to the device is not covered by the war-
ranty.
• You can buy cleaning agents from our on-
line shop.
Requirements
• The cleaning agent tank is filled with clean-
ing agent.
• 3-in-1 nozzle is at the position foam nozzle
for cleaning agent.
• The rotatable pressure setting (20) on the
trigger gun (1) is at the position high pres-
sure for walls and foam, the LC display
(15) shows .
Filling and emptying the cleaning
agent tank
1. Remove the sealing cap with suction hose
(12) from the cleaning agent tank (13).
2. Pull the cleaning agent tank up and then
away from the device.
✔ The cleaning agent tank is removed and
can be filled or emptied.
3. Insert the cleaning agent tank in reverse or-
der.
4. Seal the cleaning agent tank with the seal-
ing cap.
5. Push the suction hose into the cleaning
agent tank until it reaches the bottom.
Switching on
WARNING! A leaky water system can
result in electric shock! Move the On/Off
switch (32) to the position "0" (OFF). Pull out
the plug. Try connecting the water again (see
Establishing a water supply, p. 27).
WARNING! The device may only be used
in an upright position! There is a risk of an elec-
tric shock if the device falls over. Move the
On/Off switch (32) to the position "0" (OFF).
Pull out the plug. Only now may you bring the
device into the upright position. For your own
safety, wait about five minutes until you restore
the electrical connection.
WARNING! Unsuitable extension cables
can be dangerous! Use only extension cables
that are designed for outdoor use. The connec-
tion must be dry and routed above the ground.
We recommend using a cable drum that holds
the socket at least 60 mm above the ground.
1. Ensure that the On/Off switch (32) is in the
"0" (OFF) position.
2. Put the device in an upright position.
3. Insert the mains plug into an earthed socket
with residual current circuitry.
The right part of the holder for the mains
connection cable (11) as seen from behind
is rotatable. This allows you to easily re-
move the mains connection cable (10).
4. NOTICE! Dry running will damage the
device. Do not operate the pressure washer
with the tap turned off.
Turn the tap on fully.
5. Move the On/Off switch (32) to the posi-
tion "I" (ON).
✔ The motor switches on briefly until the
necessary pressure has built up. The motor
then stops.
WARNING! Be aware of the recoil
6.
force when the water jet commences. There
is a risk of injuring yourself or other people.
Ensure that your footing is secure. Keep a
good hold on the trigger gun (1).
Press the switch lever (17) on the trigger
gun (1).
✔ The nozzle starts working at pressure
and the motor starts. If you release the
switch lever (17), the motor stops. The high
pressure is maintained in the system.
Interrupting the operation
You can insert the trigger gun (1) with lance
and nozzle into the holder for the trigger gun
(31).
1. Release the switch lever (17) on the trigger
gun (1).
2. If you put down the trigger gun: Lock the
switch lever using the child safety lock (18)
(seen from behind).
⭠ The switch lever is locked ὑ.
⭢ You can pull the switch lever ὑ.
