GB IE
Scope of delivery/
accessories
Unpack the device and check that everything is
present.
Dispose of the packaging material properly.
• Pressure Washer with mains connection
cable
• Trigger gun
• Lance
• High-pressure hose
• 3-in-1 nozzle
• Turbo dirt blaster
• Surface cleaner
• Cleaning agent bottle (500 mℓ)
• Garden hose adaptor
• Quick connector and Filter insert
• Nozzle cleaning needle
• 2 × TRONIC Alkaline battery (1,5 V; AAA/
LR03)
• Instructions
Description of functions
The pressure washer cleans using a high-pres-
sure water jet.
If necessary, it can also be operated with addi-
tional cleaning agents.
Please refer to the descriptions below for in-
formation on how the operating elements work.
Overview
The illustrations for the device
can be found on the front fold-out
page.
Overview
1 Trigger gun
2 Bow-type handle
3 —Release
4 Lance
5 Hose reel with crank handle
6 Nozzle cleaning needle
7 Extension hose
8 High-pressure hose
22
9 Guide for high-pressure hose
10 Mains connection cable
11 Holder for mains connection cable
12 Sealing cap with suction hose
13 Cleaning agent tank
14 Wheels
15 LC display to indicate pressure
16 Battery compartment
17 Switch lever
18 Child safety lock
19 Release for high-pressure hose
20 Pressure setting
21 Quick connector
22 Turbo dirt blaster
23 3-in-1 nozzle
24 Surface cleaner
25 —Pressure regulator
26 —Pivotable connection
27 Cleaning agent bottle
28 Water connection
29 Quick connector for garden hose
30 Filter insert
31 Holder for trigger gun
32 On/Off switch
33 Holder for nozzles
34 Garden hose adaptor
35 Alkaline battery (1,5 V; AAA/LR03)
Technical data
Pressure Washer
Rated voltage U
Rated output P
Length Mains connection
cable
Protection class
Protection type
Weight
Length of high-pressure hose
Operating pressure (p)
PHDP 180 B2
230 V ∿; 50 Hz
3000 W
5 m
I
IPX5
21.6 kg
10 m
15 MPa
