The disposal and recycling of used products and packaging must
comply with the laws and regulations for waste handling in
each country. Contact your local waste management company
for information.
8 Troubleshooting
Fault Possible Cause(s)
Power is off.
Unit does Power plug is not
not operate connected.
at all There is a power
failure
CLEANSING,
BIDET, DRY,
Seat is covered.
AUTO do not
operate
Remote
Batteries in the
control does
remote control have
not operate
been exhausted.
at all
Batteries are empty
Malfunction
or too weak.
of the
Remote control out
remote
of reach of the
control
device.
The shut off valve is
closed.
No water
spray
There is water supply
outage.
The water pressure
level is set to "LOW".
Low water
The water strainer is
pressure
clogged.
Nozzle head is dirty.
The water
Low water temperature level is
temperature turned off or set to
"LOW".
The warm seat
Seat is not temperature level is
warm turned off or set to
"LOW".
The warm air dryer
Dryer air is temperature level is
not warm turned off or set to
"LOW".
9 Technical Data
9.1 General Data
Power supply
Max. power consumption
1590625-I
Remedy
Press any button to check
except "HIGH", "LOW",
"FRONT" or "BACK"
buttons of the remote
control.
Make sure that there is
nothing on the seat
surface. (The device is only
activated when the user's
skin touches the seat
sensor.)
Replace batteries with new
ones, → 4.1 Installation /
Assembly, 5.
Replace batteries with new
ones, → 4.1 Installation /
Assembly, 5.
Open shut off valve.
Restore water supply.
Increase water pressure
level, → 5.4 Using the
Shower Toilet, 8.
Clean water strainer, →
6.1.2 Cleaning Instructions,
10.
Clean nozzle, → 6.1.2
Cleaning Instructions, 10.
Turn on or increase water
temperature level, → 5.4
Using the Shower Toilet, 8.
Turn on or increase seat
temperature level, → 5.4
Using the Shower Toilet, 8.
Turn on or increase warm
air dryer temperature
level, → 5.4 Using the
Shower Toilet, 8.
220 – 240 V AC, 50/60 Hz
1725 – 2 053 W
Intermittent (periodic
operation)
Type of protection, entire
device
Length of power cord
Battery type remote control
Type water supply
connection
Ø Connection at shower
toilet
Ø T-piece
Ø Connection hose
Length connection hose
Water supply pressure
Water supply temperature
Operating temperature
Product width
Product length
Product depth
Product weight
Maximum u ser weight
1)
Protected against the penetration of water that is s plashed
against the housing from all directions (warm seat only).
Cleansing Functions
Water flow rate CLEANSING
Water flow rate BIDET
Water pressure adjustment
Temperature adjustment
Heater capacity
Safety devices
Warm Seat
Temperature adjustment
Heater capacity
Safety devices
Drying Functions
Temperature adjustment
Heater capacity
Safety devices
8 Troubleshooting
85%, 30 min. ON /5 min.
OFF
1)
IPX4
1.4 m
2 x AA (LR6) / 1.5 V
Direct c onnection to the
water supply
1/2"
1/2"- 3/8" - 1/2"
1/2" cranked to 3/8"
500 mm
79 – 735 k Pa
3 – 25 °C
3 – 40 °C
389 mm
515 mm
156 mm
3.9 kg
125 kg
0.7 l/min
0.85 l/min
3 levels
Normal water supply
temperature, 34 °C, 37 °C,
40 ° C
1670 – 1987 W
Thermal fuse, Thermostat
Room temperature,
35 °C, 38 °C, 40 °C
55 – 65 W
Thermal fuse
Room temperature –
50 °C (5 levels)
195 – 232 W
Thermal fuse, Bi-metal
