Specifications
Processing
Input processing channels
Output processing channels
Internal effects engines (all true stereo)
Point-to-point routing matrix
Signal processing
A/D converters (8-channel, 48 kHz, 24 bits)
D/A converters (stereo, 48 kHz, 24 bits)
I/O latency (console input to output)
Network latency (stage box in > console > stage box out)
Connectors
Midas PRO series microphone preamplifier (XLR)
XLR balanced outputs
Aux inputs/outputs (¼" TRS balanced, mono)
Phones output (¼" TRS, stereo)
Digital AES/EBU input/output (XLR)
AES50 ports (Klark Teknik SuperMAC, 100 Mbit/s)
Expansion card interface
StageConnect HOST(Master) I/O (12 V / 18 W power supplied, XLR, 32 channels)
MIDI inputs/outputs
GPIO on TRS, configurable
USB 2.0 type B device (48 x 48 ch 24-bit audio and MIDI I/O)
USB 2.0 type A host (audio and data, 5 VDC, 1 A)
Ethernet LAN ports, RJ45, 1 Gbit/s
Audio over IP (AoIP) internal module socket
(Dante, AES67 or SoundGrid modules optional)
IEC mains socket with power switch
Mic Input Characteristics (Mic Input to Analog Output)
Design
THD+N (0 dB gain, 0 dBu output)
THD+N (+40 dB gain, 0 dBu to +20 dBu output)
Input impedance (unbalanced / balanced
Non-clip maximum input level
Phantom power (switchable per input)
Equivalent input noise @ +45 dB gain (150 Ω source)
CMRR @ unity gain (typical)
CMRR @ 40 dB gain (typical)
Input/Output Characteristics
Frequency response @ 48 kHz sample rate, 0 to -1 dB (any gain setting)
Dynamic range, analog in to analog out (typical), XLR / aux
A/D dynamic range, preamplifier and converter (typical), XLR / aux
D/A dynamic range, converter and output (typical), XLR / aux
Crosstalk rejection @ 1 kHz, adjacent channels
Output level, XLR connectors (nominal / maximum)
Output impedance, XLR connectors (unbalanced / balanced)
Input impedance , TRS connectors (unbalanced / balanced)
Non-clip maximum input level, TRS connectors
Aux output level, TRS (nominal / maximum)
Aux output impedance, TRS (unbalanced / balanced)
Headphone output impedance / maximum output level
Residual noise level, XLR out 1-16 connectors, unity gain
Residual noise level, aux and monitor TRS out connectors
40 stereo input channels, 8 stereo aux channels
16 stereo aux buses, 8 stereo matrices, 4 stereo mains
8 premium FX slots, 8 standard FX slots
500 x 502 signals
40-bit floating point, 48 kHz
114 dB dynamic range*
120 dB dyanmic range*
1.0 ms
1.2 ms
24
8
N/A
5
1 / 1
3
64 x 64 channel audio input / output
1
1 / 1
2 x 2
1
1
2, internally switched
Up to 64 x 64 channels @ 48 kHz
1
Midas PRO series
<0.004%*
<0.006%*
1 kΩ / 2 kΩ
+21 dBu
+48 V
-128 dBu*
>50 dB
>70 dB
10 Hz - 20 kHz
111 dB* / 108 dB*
112 dB* / 110 dB*
118 dB* / 112 dB*
100 dB
+4 dBu / +21 dBu
75 Ω / 75 Ω
N A
/
N A
/
N A
/
N A
/
500 mW @ 75 Ω / +18 dBu
-97 dBu*
N A
/
Displays
Main screen
Main screen swivel, continuous adjustment
4-channel group LCD screen with RGB color strip per channel
Channel editing screen
Button assignment screen
Main stereo meter
Controls
100 mm motor faders
Touch-sensitive rotary controls
Custom Controls
Fully assignable rotary controls
Fully assignable backlit buttons
Variable rotary controls / buttons
Power
Switch-mode power supply
Power consumption
Physical
Standard operating temperature range
Dimensions (H x W x D)
Weight
*A-weighted noise and dynamic range figures
Quick Start Guide 209
10.1" TFT LCD, 1280 x 800 px, capacitive touch
0°- 45°
320 x 48 monochrome
N/A
N/A
18 segment (-60 dB to clip)
N/A
1 + 4 + 1
4
8
N/A
Auto-ranging 100-240 VAC (50/60 Hz)
130 W
5°C – 45°C (41°F – 113°F)
183 x 326 x 486 mm (7.2 x 12.8 x 19.1")
9.5 kg (20.9 lbs)
