position as the engine warms up. After engine warms up, pull throttle lever to accelerate engine speed and
place the shift stick at the desired position. Plate will begin vibrating and proceed with compacting.
4.3.1.
Operating
Do not operate plate on concrete or on extremely hard, dry, compacted surfaces. The plate will
jump rather than vibrate and could damage both plate and engine.
1. After engine warms up, pull throttle lever to accelerate engine speed. Plate will Begin vibrating and
move forward.
2. The plate compactor is designed to run at an engine speed (engine take off shaft) of 3600 rpm
(Normally considered full throttle). Running the engine at lower rpm's will result in a decrease of
compaction force and lower travel speed. It will create excessive "out-of-synch" vibrations resulting in
poor compaction, manoeuvrability, excessive wear to the machine, and discomfort to the operator.
3. In operation, guide the machine, but let the compactor do the work. Bearing down on the handle is
unnecessary and causes shock absorber wear.
4. On level surfaces the compactor moves forward rapidly. On uneven surfaces or inclines, light forward
pressure on handle may be required to assist the compactor in moving forward.
5. The number of passes required to reach a desired compaction level will depend on the type and
moisture content of soil. Maximum soil compaction has been reached when excessive kickback is
noticed.
When using a compactor on asphalt, Water Sprinkler Kit is required to help prevent the bottom
plate from adhering to the hot asphalt surface.
When using plate on paving stones, attach a pad to the bottom of the plate to prevent chipping or
grinding surface of the stones. A special urethane pad designed for this purpose is available as an
optional accessory.
While a certain amount of moisture in the soil is necessary, excessive moisture may cause soil
particles to stick together and prevent good compaction. If soil is extremely wet, allow it to dry
before compacting.
If soil is so dry as to create dust clouds while operating plate, some moisture should be added to
the ground material to improve compacting. This will also reduce service to the air filter.
Stopping Engine
To stop the engine in an emergency, simply turn the engine switch to the OFF position. Under normal
conditions, use the following procedure.
1. Move the throttle lever to the SLOW position.
2. Let engine idle for one or two minutes.
3. Turn the engine switch to the OFF position.
4. Turn the fuel valve lever to the OFF position.
Do not move choke control to CLOSE to stop engine. Backfire or engine damage may occur.
Idle Speed
Set throttle control lever to its "low" position to reduce stress on the engine when compacting is not being
performed. Lowering the engine speed to idle the engine will help extend the life of the engine, as well as
conserve fuel and reduce the noise level of the machine.
EN
