Energi Savr Node QS
Procedure for assigning DALI buses to QS keypads
WARNING! Danger of Shock. May result in serious injury or death. DO NOT WIRE WHEN LIVE! Switch off power via
circuit breaker or isolator before wiring or servicing the Energi Savr Node QS.
Buttons and LEDs on the front of the unit are used for programming and troubleshooting. If wiring is exposed when
accessing buttons and LEDs, the unit must be accessed by a certified electrician, following local codes.
1. Enter QS keypad into programming mode (press and hold top and bottom buttons until the LEDs on the QS keypad start
scrolling).
2. Lights on buses previously assigned to this QS keypad will go to low-end. Unassigned buses will go to high-end.
3. To assign DALI Buses to a QS keypad:
a. Identifying buses
i. Single-tap DALI 1 button to select bus 1. Ballast(s) on bus 1 starts flashing. DALI 1 LED starts flashing.
ii. Single-tap DALI 2 button to select bus 2. Ballast(s) on bus 2 starts flashing. DALI 2 LED starts flashing.
iii. If a bus is flashing single-tapping that bus again will cause it to stop flashing
b. Assigning buses to the control
i. After you determining which bus (ex: bus 1) you want to assign to the control, Press and hold the corresponding bus
button (ex: DALI 1 for bus 1) until the LED corresponding to the button (ex: DALI 1 LED) starts to flutter, approximately
3 seconds.
ii. Release the button. The ballast(s) on the assigned bus will go to low-end if successful.
iii. The corresponding LED goes ON if the assignment was successful.
c. Un-assigning buses
i. If a bus is assigned (ex: bus 1), Press and hold the corresponding bus button (ex: DALI 1 for bus 1) until the LED cor-
responding to the button (ex: DALI 1 LED) starts to flutter, approximately 3 seconds.
ii. Release the button. The ballast(s) on the assigned bus goes to high-end if successful.
iii. The LED goes OFF if the un-assignment was successful.
4. Exit programming mode from QS keypad (press and hold top and bottom buttons until the LEDs on the QS keypad stop
scrolling). All lights should go to their previous levels (levels before entering programming mode).
Procedure for verifying DALI lights connected to DALI bus 1 and bus 2:
1. Enter Test mode: - Press and hold Test Button until Test LED starts flashing.
DALI 1 button:
Each button press cycles the lights between:
• Bus 1 going to high-end,
• Bus 1 going to low-end, and
• Bus 1 flash.
2. Exit Test mode: press and hold Test button until Test LED stops flashing.
Energi Savr Node QS DALI Installation Guide
TM
DALI | Installation Guide
TM
:
DALI 2 button:
Each button press cycles the lights between:
• Bus 2 going to high-end,
• Bus 2 going to low-end, and
• Bus 2 flash.
|
Lutron 13
®
