Lutron GRAFIK Eye QSGRJ-3P Bedienungsanleitung

®
Please Read
The GRAFIK Eye QS control unit allows for control
®
of both lights and shades, without interfaces, using
a single control unit. Features include pushbutton
scene recall, info screen that displays energy savings
and status, IR receiver, astronomic timeclock, contact
closure input, and engravable backlit buttons that are
easy to find and operate.
Model Numbers: QSGRJ-3P, QSGRJ-4P, QSGRJ-6P
QSGR-3P, QSGR-4P, QSGR-6P
Unit Capacity (watts)
MLV
Zone Capacity (watts)
MLV
See page 6 for IEC PELV/NEC
English
Español
Control Unit
LUTRON
120 V 220 - 240 V
50/60 Hz 50/60 Hz
2000 W 3000 W
2000 VA 3000 VA
1600 W 2400 W
25 – 800 W 40 – 1200 W
25 – 800 VA 40 – 1200 VA
25 – 600 W 40 – 960 W
Class 2 ratings.
®
Français
Quick Installation
and Operation Guide
Contents
Features and Functions of the
GRAFIK Eye QS Control Unit
®
Wiring the GRAFIK Eye
Overview of Line Voltage/Mains Wiring . . . . . . . . . 3
Line Voltage Wiring Details . . . . . . . . . . . . . . . . . . . 4
Overview of IEC PELV/NEC
QS Link Control Wiring Details . . . . . . . . . . . . . . . . 7
Power Group Wiring Example . . . . . . . . . . . . . . . . 8
Completing Installation of the
GRAFIK Eye QS Control Unit . . . . . . . . . . . . .
®
Programming Mode
Entering and Exiting Programming Mode . . . . . . 10
Navigating Menus in Programming Mode . . . . . . 10
Wireless Mode . . . . . . . . . . . . . . . . . . . . . . . . .
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Zone Setup
Assigning Load Types . . . . . . . . . . . . . . . . . . . . . . 12
Assigning Non-Dim Load Type . . . . . . . . . . . . . . . 12
Setting Load Types . . . . . . . . . . . . . . . . . . . . . . . . 13
Scene Setup
Setting Zone Levels, Fade Rates,
and Shade Group Actions . . . . . . . . . . . . . . . . . 14
Occupancy Sensor Setup . . . . . . . . . . . . . . . .
Scene Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Configuring Occupancy Sensor Settings
(optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Pico Wireless Control Setup:
®
Associating with a GRAFIK Eye
Wireless Control Unit . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . .
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contact Information . . . . . . . . . . . . . . . . . . . .
For additional features and advanced functions,
see the complete installation and operation guide at
www.lutron.com/qs
For California residents only:
The batteries in these devices contain
Perchlorate Material – special handling may apply.
For more information visit
www.dtsc.ca.gov/hazardouswaste/perchlorate
