M A I N T E N A N C E A N D C A R E
R E M O V I N G A N D M O U N T I N G T H E W H E E L
R E M O V I N G T H E W H E E L
Detach the link (1) on the
3
brake lever (if necessary,
screw the adjustment screw (2) in
somewhat until the link can be
detached).
» Grab the adjustment screw (2) and
remove the entire brake cable unit
from the brake anchor plate.
Rear wheel only: Remove the
4
screw (4) on the frame clamp.
» Attachment using axle nuts: To
remove the wheel, remove both
axle nuts (3).
» Attachment using quick-release:
To remove the wheel, open the
quick-release lever.
8
3
3
4
4
