Fig.
d
Using the screws (S13), mount a preas-
sembled roller block (88L/88R) on the left and right of
the top section (87). In doing so, observe the per-
missible torque of 10 Nm.
4.5.8 Mounting the middle hinges
Fig.
a
, page A16. After the assembly of the indi-
vidual door leaf sections (44;67;86;87), mount the
middle hinges (48) using the screws (S13). In doing
so, observe the permissible torque of 10 Nm.
4.6
Installing the tension springs
4.6.1 Suspending the wire cables
Fig.
a
and Fig.
b
push it in its end position. Secure the door leaf on
both sides against sinking.
Fig.
c
Match each of the two wire cable ele-
ments (12) to the respective door side. Align the wire
cable elements (12) in a way that the left frame indic-
ates the red surface and the right frame indicates the
black surface.
Fig.
d
Insert the double end of the wire cable (12)
into the rope holder (4L/4R). Make sure that the wire
cables do not cross each other.
Fig.
e
Place the single ends of the wire cable (12)
around the deflection roller (17) and mount the de-
flection roller (17) with the screw (S15) to both sides
of the tail end (16L/16R). In doing so, make sure that
the two wire cables run parallel to each other. The
wire cables must not cross each other.
Fig.
f
Guide the two single ends of the wire
cable (12) to the rope swing device on the lower rope
mounting (57L/57R) of the bottom section (44).
Thread the ends of the wire cable (12) into the rope
swing device one by one, making sure that the wire
cables run parallel to each other.
Fig.
g
Mount the wire cable guide (21) to the rope
holder (4L/4R) with the screw (S17). Position the two
wire cables (S12) behind the wire cable guide (21)
and make sure they run parallel to each other.
4.6.2 Suspending the tension springs
Hazardous tensioned spring!
WARNING
After installation and after each adjust-
ment, the spring assembly must be se-
cured with the R-pin!
Fig.
a
, page A17. Hook the slot of the spring as-
sembly (11) into the lower spring suspension (5) and
secure it with the R-pin (15).
Fig.
b
Then hook the lug of the spring assembly (11,
slightly prestressed) into the spring tensioning
strap (12). Secure the spring assembly (11) with an
R-pin (15).
To determine the optimum tension of the tension
spring, open the door halfway. The door must be able
to maintain this position. You can adjust the spring
force by repositioning the lug of the spring tensioning
strap (12).
24 - EN
, page A16. Lift the door leaf and
4.6.3 Completing the installation of the door leaf
Fig.
a
Depending on the type of door operation, it
may be necessary to mount guide plates (99).
Hand operation: Mount one guide plate (99) to the
frame on each side of the door.
NovoPort drive: Mount one guide plate (99) to the
frame on the NovoPort drive side only.
Ceiling pull: It is not necessary to install a guide
plate (99).
Proceed as follows to mount a guide plate (99):
Swing
the
guide
frame (1L/1R) and connect it with the screw (S3).
Fig.
b
Close the door to make final adjustments on
the upper track rollers. Make sure that the mounting
blocks under the door leaf have been removed.
Fig.
c
For hand operation or NovoPort drive: Posi-
tion the centres of the track roller in a way that it is
centrally aligned with the inner edge of the tail end.
Observe that the track rollers must be positioned by
approx. 25 mm to the top when operating the system
with a ceiling pull drive.
After having adjusted the upper track roller, tighten
the screws on the roller holder (105L/105R).
Fig.
d
In order to complete the assembly, carefully
insert the safety guard (39) on both sides of the rails.
Fig.
e
Check the frame and shutter seals for any de-
formation. Their original shape can be restored with a
hot air gun or similar.
4.7
Additional assembly options for hand
operation
4.7.1 Mounting the manual cable (optional)
Risk of injury caused by
WARNING
strangulating limbs
If manual cable and door drive are both
installed in the system, there is a risk of
limbs getting caught and strangulated by
the manual cable when moving the door.
•
If the door drive is already installed
or shall be installed, the manual
cable must not be mounted!
Fig.
a
, page A19. Mount the cable holder (91) for
the manual cable (96) on the bottom section (44) us-
ing the screws (S10). In doing so, observe the per-
missible torque of 10 Nm.
Fig.
b
Feed the manual cable (96) through the re-
spective hole in the cable holder (91) and secure it
with a knot.
Fig.
c
Suspend the manual cable (96) on the con-
necting plate (18), also by tying a knot.
4.7.2 Mounting the rail clamps
Manually open the door and mark the end position of
the uppermost track roller (105L/105R).
Fig.
a
, page A19. Close the door and mount the rail
clamps (89) with the screws (S14) on the marked po-
sition.
These assembly, operation and maintenance instructions must be kept for the entire period of use!
plate (99)
into
the
angle
