Inbedrijfname
Bedrijfsstand
Bedrijfsgereed
Test Brander
Lucht :
Aanloop
Lucht :
Test Luchtdruk
Lucht :
Voorventilatie : 20 s
Lucht :
Voorontsteking
Lucht :
Veiligheidstijd
Lucht :
Stabilisatietijd
Lucht :
Bedrijf
Lucht :
50
Brander gereed
Ketelthermostaat vraagt warmte.
Afloopschema branderstart :
Gas :
Brander start met de volgende funktieafloop :
Luchtklep wordt voor ventileren open gestuurd. Lucht : . . . . . . . . . .
Gas :
Ventilatormotor in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas :
Voorventilatie 20 sec. : resterende tijd wordt aangegeven.
Gas :
Gasregelklep gaat naar startstand. Gas : . . . . . . . . . . . . . . . . . . .
Luchtklep gaat naar startstand. Lucht : . . . . . . . . . . . . . . . . . . . . .
Gas :
Ontsteking in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gasklep onder spanning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas :
Veiligheidstijd 3 sec.
Vlamvorming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Na de veiligheidstijd wordt de ontstekingstrafo spanningsloos.
Gas :
· Tijdens de stabilisatietijd blijft de brander in de startstand.
· De brander is in bedrijf en regelt in de ingegeven belastingsband bu tot bo.
Gas :
De actuele stand van de luchtklep wordt aangegeven.
