Dimensions
RTN/M2LB - Version with pendulum bearing
Max. capacity 10 t ... 22 t
65
only version with stay rod
View from above
130
View from below
130
20
148
255
18
140
310
20
140
310
A01867_02_YS0_02 HBM: public
max. 5 spacer plates
20
20
10
Perspective view
Dimensions in mm
(1mm = 0.03937 inches)
RTN/M2...
