3-5. Service Setup
39. Pump maximum speed
Normally setting is not necessary.
Please adjust when need to reduce the pump sound etc.
Besides that, it has Air Purge function.
When *Pump fl ow setting is Max. Duty, this duty set is the fi x pump duty run
during room side operation.
40. Pump down
Operate pump down operation
41. Dry concrete
Operate concrete curing operation.
Select Edit, set temp for every stage (1~99 1 is for 1 day).
Setting range is 25~55°C
When it is turned ON, dry concrete starts.
When it is 2 zone, it dries both zones.
42. Service contact
Able to set name & tel no. of contact
person when there is breakdown
etc. or client has trouble. (2 items)
3-6. Remote control setup
43. RC selection
Set to "Single" when only one remote controller is installed.
Set to "Dual" when two remote controllers are installed.
Initial setting: Depend on model
Service setup
Pump down:
Service setup
Service contact:
Select
Initial setting : Single
12:00am,Mon
ON
Confi rm
40°C
35°C
30°C
1 2
12:00am,Mon
Contact 1
Contact 2
Confi rm
Service setup
Flow rate Max. Duty
88:8 L/min 0xCE
Select
Service setup
Pump down operation
Pump down:
in progress!
ON
OFF
Confi rm
45°C
40°C
35°C
3 4 5 6
Contact-1: Bryan Adams
ABC/ abc
A B C D E F G H I J K L M N O P Q R
S T U V W X Y Z a b c d e f g h i
j k l m n o p q r s t u v w x y z
Select
RC selection
Single
Dual
Select Confi rm
12:00am,Mon
Operation
Air Purge
1212:00am,Mon
Stage
0-9/ Other
Enter
12:00am,Mon
