17 Technical Information

RS 232/RS 485 Communication Description

Tab. 5
PIN N.
1
2
3
4
5
6
7
8
9
A serial communication kit with a serial cable and the Navigation
software is available (optional).

RS 232/RS 485 Communication Description

Both the RS 232 and the RS 485 interfaces are available on the
connector J2.
The communication protocol is the same (see the structure below),
but only the RS 485 manages the address field. Therefore to enable
the RS 485 is necessary to select the type of communication as well
as the device address by means of the software.

Communication Format

▪
▪
▪
▪
298/318
SIGNAL NAME
+5 V (OUT)
TX (RS232)
RX (RS232)
Not used
GND
A + (RS485)
Not used
B - (RS485)
Not used
8 data bit
no parity
1 stop bit
baud rate: 600/1200/2400/4800/9600 programmable
