1. Remove the engine cover (3) (Fig. 7).
2. Remove the air filter cover by pressing the fasten-
ing tabs on the side.
3. Remove the air filter (22).
4. Do not use harsh cleaners or petrol to clean the
filter.
5. Clean the elements by knocking them out on a flat
surface. If heavily soiled, wash with soapy water,
then rinse with clean water and allow to air dry.
6. The re-assembly takes place in reverse order.
10.2.4 Spark plug (Fig. 11 + 12)
m ATTENTION: Only replace the spark plug when
the engine is cold!
Check the spark plug (22) for contamination for the first
time after 20 operating hours and clean it with a copper
wire brush if necessary. Then maintain the spark plug
(22) every 50 operating hours.
1. Open the spark plug cover (4).
2. Pull off the spark plug connector (24) with a twist-
ing motion.
3. Remove the spark plug (23) with the enclosed
spark plug wrench (18).
4. Remove any dirt from the base of the spark plug
(23).
5. Visually inspect the spark plug (23). Remove any
deposits present using a wire brush.
6. Check the spark plug gap. Set the electrode gap to
0.6 to 0.7 mm with a feeler gauge.
7. The re-assembly takes place in reverse order.
NOTE
A loose spark plug can overheat and cause damage
to the engine. Tightening the spark plug too much can
damage the thread in the cylinder head.
10.2.5 Clean the fuel filter insert (Fig. 13 + 14)
Note: The fuel filter insert (25) is a filter cup which is
located directly under the tank cover (2) and filters all
the fuel filled in.
1. Set the on/off switch (11) to the "OFF" position.
2. Open the fuel filler cap (2).
3. Remove the fuel filter insert (25) and the fill level
marking (26). Clean it in a non­flammable solvent
or a solvent with a high flash point.
4. Reinsert the fuel filter insert (25) with the fill level
marking (26).
5. Close the tank cover (2).
34 | GB
Please provide the following information in the
event of any enquiries:
• Machine data - type plate
• Engine data - type plate
Important note in the case of repairs:
For return delivery of the device for repair, please en-
sure for safety reasons that it is free of oil and fuel when
it is sent to the service centre.

10.3 Ordering spare parts

Please provide the following information when ordering
spare parts:
• Device type
• Device article number

Service information

With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consuma-
bles.
Wearing parts*: Spark plug, air filter
* may not be included in the scope of delivery!
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.

11. Storage

11.1 Preparation for storage

1. Empty the fuel tank using a petrol extraction pump
(see section 11.2).
Warning: Do not remove the petrol in enclosed
spaces, near fire or when smoking. Petrol fumes
can cause explosions and fire.
2. Change the oil at the end of every season.
3. To do so, remove the used engine oil from a warm
engine and refill with fresh oil.
4. Remove the spark plug (23). (Fig. 12)
5. Fill the cylinder with approx. 20 ml of oil from an
oil can.
6. Pull the start pull cord slowly so that the oil pro-
tects the inside of the cylinder.
7. Screw the spark plug (23) back in.
8. Store the device in a well-ventilated place or area.
11.2 Drain petrol with a petrol extraction pump
In the case of storage over a longer period of time, the
petrol must be drained.
