DANGER! Risk of injury during installa-
tion! No parts may be installed or removed
unless the motor has been turned off and
cooled down.
The machine can be operated with different trimming
heads according to the purpose for which it is being
used:
• Impact knife: exclusively for trimming open
areas with strong growth such as: Weeds, high
grass, undergrowth, bushes, weed growth,
scrub, etc.
• Filament head: exclusively for trimming grass. It
can be used along walls, fences, lawn edges,
trees, posts, etc.
Connect both shaft tubes
► P. 4, item 3
– Push the lower shaft pipe (7) into the upper shaft
pipe (5).
– Slightly turn the shaft pipes against one another
until the locking bolt (21) audibly engages.
– Tighten the clamping screw (22).
Fitting the operating bar
► P. 4, item 3
– Screw down both halves of the operating handle
(4) using the screws (23) as illustrated.
Fitting the shoulder strap
► P. 4, item 3
– Hook the shoulder strap into the lug (2) on the
shaft tube.
Fitting the protective hood
► P. 4, item 3
– Use screws (24) to screw the protective hood (8)
to the trimming head (9)
Fitting the knife
DANGER! Risk of injury during installa-
tion! The knife is sharp. Wear cut-resistant
work gloves when installing the knife.
– Remove and store the knife transport guard (e.g.
when storing the machine).
► P. 4, item 5
– Insert a suitable object (Allen key etc.) as shown
and hold it in the hole (26).
– Unscrew the hexagon nut (27) by rotating clock-
wise. Caution: Left hand thread!
– Remove the blade flange (28).
► P. 5, item 6
– Attach the blade (29).
– Attach the blade flange (28).
– Tighten the hexagon nut (27) in counter-clock-
wise sense. Caution: Left hand thread!
Fitting the filament spool
DANGER! Danger of injury! There is a
sharp knife for trimming the filament on the
underside of the filament hood. Remove the
transport packaging only after installation.
► P. 4, item 4
– Remove the transportation protection mecha-
nism from the cutting blade (25).
► P. 4, item 5
– Insert a suitable object (Allen key etc.) as shown
and hold it in the hole (26).
– Unscrew the hexagon nut (27) by rotating clock-
wise. Caution: Left hand thread!
– Remove the blade flange (28).
► P. 5, item 7
– Place the filament spool (30) on the drive shaft,
and turn it hand tight in an anticlockwise direc-
tion. Caution: Left hand thread!)

Operation

Filling with fuel
DANGER! Danger of injury! Fuel is explo-
sive!
– Turn off and cool the motor down
before filling the tank with fuel.
– You must observe all safety instruc-
tions relating to handling fuel.
Note: Stipulated fuel (► Approved fuels –
p. 49)
► P. 3, item 2
– Lay down the machine safely with the tank cap
facing up.
– Before opening the tank, clean the tank cap and
the filler nozzle if necessary.
– Slowly turn the tank cap (19) open and remove it.
– Slowly fill in the fuel mix. Avoid spilling!
– Check the seal inside the tank cap for damage
and replace it if necessary. Replace a damaged
seal immediately!
– Tighten the tank cap and seal by hand.
– In case you spilled some fuel: make sure to wipe
off the fuel.
Check the safe condition of the machine:
– Check the machine for leaks.
Check before use!
DANGER! Attention, danger of injury! Do
not operate the machine unless you did not
find any faults. If a part has become defec-
tive, make sure to replace it before you use
the machine again.
Check the safety devices and the safe condition of
the machine (especially tightening knob, protective
hood and trimming head):
– Check the machine for visual damage: broken
parts, cracks, etc.
– Check that all parts of the machine have been
securely fitted.
– Check that all safety devices are in proper con-
dition.
– Check that there are no leaks.
– Remove the knife transport guard.
