Fault/malfunction
Motor will not stop.
Motor runs too quickly.
Excessive formation of exhaust gas/
smoke
Trimming performance insufficient. Blade blunt?
Filament does not feed out auto-
matically.
Trimming tool is rotating during
idling even though the throttle has
not been operated.
If you can't fix the fault yourself, contact your nearest
vendor. Please be aware that any improper repairs
will also invalidate the warranty and additional costs
may be incurred.

Disposal

Disposal of the appliance
WARNING! Risk of fire or environmental
damage! Avoid damage caused by leaking
fuel: drain the tank prior to disposal.
This appliance must not be disposed of with regular
household waste! Dispose of the appliance in the
appropriate manner. For more information, consult
your community waste disposal service.
Disposing of fuels and lubricants
Waste fuels, waste oils, and materials containing oils
(air filter, rags, etc.) may not get into the environment.
– Bring waste materials that could damage the
environment to a collection point of the dealer or
in your community.
Disposal of the packaging
The packaging consists of cardboard and
correspondingly marked plastics that can
be recycled.
48
Cause
Spark plug is soiled (is the tip black-
ened with soot)?
Is the distance between the elec-
trodes of the spark plug too large?
Wrong fuel or mixture?
Incorrect carburettor setting?
Spark plug: Is the electrode light
grey and does it show signs of com-
bustion?
Motor is too cold?
Filament is too short?
Wrong fuel mix?
Carburettor mixture set incorrectly Have the carburettor adjusted.
Filament used up?
Filament spool blocked?
Idling speed too high?
Throttle stop engaged?
– Make these materials available for recycling.

Technical data

Item number
Motor stroke volume
Maximum motor output
Idling speed
Max. motor speed
Tank volume
Fuel consumption
Max. rotational speed for cut-
ting
• Impact knife
• Filament spool
External diameter of knife
Diameter of knife mount
Diameter of cutting area when
operating with a filament
Filament diameter
Required filament length
Remedy
Clean the spark plug.
Set the gap to 0.6 to 0.7 mm.
Drain the tank and fill with the cor-
rect mixture.
Have the carburettor adjusted.
Insert a spark plug with higher tem-
perature resistance.
Let the motor warm up slowly; if
necessary, set the choke lever
slightly higher.
► Extending the filament – p. 45
Fill with stipulated fuel.
Turn (only possible with suitable
knives) or replace the knife.
Have the knife sharpened by an au-
thorised workshop.
► Replacing the filament – p. 46.
Eliminate the cause of the blockage
(► Removing the filament spool –
p. 46).
Have the carburettor adjusted.
Briefly press the throttle firmly to re-
lease the throttle stop.
401 118, 401 119
25 cm³
0,75 kW
−1
3000 min
−1
10000 min
500 ml
455 g/kWh
−1
8000 min
−1
7500 min
230 mm
25,4 mm
400 mm
2,5 mm
4 m
