Cutting data brush cutter
Cutting circle diameter of
blade mm
Cutter balde thickness mm
Teeth quantity
Maximum speed brush cutter
min
-1
Cutting data hedge trimmer
Cutting circle diameter mm
Angle adjustment °
Cutting length mm
Max. cutting speed max.
min
-1
Cutting data pole saw
Guide bar length mm
Cutting length mm
Guide bar type
Chain pitch "
Saw chain type
Chain link thickness mm
Oil tank capicity cm
3
Power unit
Displacement cm
3
Max. engine output kW
Idle speed min
-1
Fuel tank capicity cm
3
Engine type
Weight grass trimmer kg
Weight brush cutterr kg
Weight pole saw kg
Weight hedge trimmer kg
Subject to technical changes!
Information concerning noise emission measured
according to relevant standards:
Sound pressure L = 94 dB(A)
pA
Sound power L = 114 dB(A)
WA
Uncertainty K = 3 dB(A)
PA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Grass trimmer vibration A = 4,8 m/s
hv
Brush cutter vibration A = 4,12 m/s
hv
Hedge trimmer vibration A = 4,77 m/s
hv
Pole saw vibration A = 4,32 m/s
hv
Uncertainty K = 1,5 m/s
2
PA
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch off the equipment when not in use.
• Wear gloves.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
255
1.4
3
7200
24
+90°/0°/-75° (165°)
400
1550
305
254
Oregon
100SDEA318
3/8"
91PJ040X
1.27
125
32.6
0,9
3000 ±200
900
2-stroke engine,
air-cooled
7.2
7.2
7.1
7.7
2
2
2
2
In these operating instructions we have marked the
places that have to do with your safety with this
sign: m

7. Before starting the equipment

Each time before use, check the following:
• That there are no leaks in the fuel system.
• That the equipment is in perfect condition and
that the safety devices and cutting devices are
complete.
• That all screws are securely fastened.
• That all moving parts move smoothly.
Fuel and oil
1
Recommended fuels
Use only a mixture of unleaded petrol and special
2-stroke engine oil. Mix the fuel mixture as indica-
ted in the fuel mixing table.
Important: Do not use a fuel mixture which has
been stored for longer than 90 days.
Important: Never use 2-stroke oil with a recom-
mended mixing ratio of 100:1. The manufacturer's
warranty
will be voided in case of engine damage due to in-
adequate lubrication.
Important: Only use containers designed and ap-
proved for the purpose to transport and store fuel.
Pour the correct quantities of petrol and 2-stroke oil
into the mixing bottle (see scale printed on the bott-
le). Then shake the bottle well.
Never use oil for 4-cycle engine or use water cooled
2-cycle engine. It can cause spark plug fouling ex-
haust part blocking or piston ring sticking.
Mixed fuels, which have been left unused for a pe-
riod of one month or more, may clog the carburetor
or result in the engine foiling to operate property. Put
remained fuel into an airtight container and keep it in
the dark and cool room.
Fuel mixing table
2
Mixing procedure: 40 parts petrol to 1 part oil
Example:
1 l Petrol : 0,025 l 2-stroke oil
5 l Petrol : 0,125 l 2-stroke oil
Warning!
Take care of the emission of exhaust gases.
Always shut off engine before fueling. Never add
fuel to a machine wi
th a running or hot engine. Take
care of fire!
GB | 33
