CAD-COMPACT ADVANCED
Modbus
Register
address
description
125
Supply air temperature low
limit
126
Low temperature detection
time
127
Filters contamination detection
time
128
Anti-freeze procedure settings
129
Pre-set exhaust air fan control
during anti-freeze procedure
130
Pre-set supply air fan con-
trol at start of the anti-freeze
procedure
131
Pre-set supply air fan control
during anti-freeze procedure
132
Anti-freeze procedure turn ON
temperature
133
Anti-freeze procedure turn OFF
hysteresis
134
Lowest detection time to start
anti-freeze procedure
135
Supply air fan lower set point
136
Exhaust air fan lower set point
137
Supply air fan higher set point
138
Exhaust air fan higher set point 50
139
Supply air fan stop delay (after
heater work)
140
Exhaust air fan stop delay
(after heater work)
141
Supply fan start delay
142
Exhaust fan start delay
143
Source channel for measure-
ment differential pressure in
supply air duct
144
Differential pressure measured
by external sensor corres-
ponding to minimum voltage
processed by AIN 1
145
Differential pressure measured
by external sensor corres-
ponding to maximum voltage
processed by AIN 1
146
Minimum voltage processed
by AIN1
147
Maximum voltage processed
by AIN1
148
K factor for supply air fan
149
Source channel for measure-
ment differential pressure in
exhaust air duct
150
Differential pressure measured
by external sensor corres-
ponding to minimum voltage
processed by AIN 2
151
Differential pressure measured
by external sensor corres-
ponding to maximum voltage
processed by AIN 2
DEUTSCH
Value
Min.
Max.
Def.
1
25
5
1
15
3
0
60
30
0
1
1
Dyn.*
Dyn.*
70
Dyn.*
Dyn.*
70
Dyn.*
Dyn.*
30
-10
10
3
1
10
3
0
5
2
0
50
25
0
50
25
50
100
100
100
100
1
20
2
0
20
2
0
200
0
0
200
0
0
1
1
0
1000
1000
0
1000
0
0
10
0
0
10
10
0
1000
84
0
1
1
0
1000
1000
0
1000
0
CAD COMPACT ADVANCED
Register
Variable
Notes
options
type
R/W
integer
Unit: °C
R/W
integer
Unit: min.
R/W
integer
Unit: sec.
R/W
integer
0 – procedure turn OFF
1 – procedure turn ON
R/W
integer
Unit: %
R/W
integer
Unit: %
R/W
integer
Unit: %
R/W
integer
Unit: °C
R/W
integer
Unit: °C
R/W
integer
Unit: min.
R/W
integer
Unit: %
R/W
integer
Unit: %
R/W
integer
Unit: %
R/W
integer
Unit: %
R/W
integer
Unit: min.
R/W
integer
Unit: min
R/W
integer
Unit: sec.
R/W
integer
Unit: sec.
R/W
integer
0 – internal sensor ΔP1
1 – external sensor connected to AIN1
R/W
integer
Unit: Pa
R/W
integer
Unit: Pa
R/W
integer
Unit: V
R/W
integer
Unit: V
R/W
float
Einstellungen resolution: 0.1; to modify the
parameter please send: requested value x 10
R/W
integer
0 – internal sensor ΔP2
1 – external sensor connected to AIN2
R/W
integer
Unit: Pa
R/W
integer
Unit: Pa
Seite 55
