ENGINE OIL FILTERS CHECK/CLEANING (DIESEL version)

1. Drive the machine on a level ground and engage the
parking brake.
2. Turn the ignition key (51) to "0".
3. Open the engine compartment hood (19) and fasten it with
the support rod (47).
4. Lift and remove the left side panel (32).
5. Remove the bolt (A, Fig. 26).
6. Remove the cap (B) and remove the oil filter (C).
7. Clean the oil filter, or replace it if damaged.
8. Install the oil filter (C).
9. Ensure that the oil filter plug (B) is completely inserted.
10. Install and tighten the retaining bolt (A).
11. Add engine oil as recommended (see the technical
characteristics table and the engine manual).
CAUTION!
See the Engine Oil Level Check paragraph for the
oil top-up procedure.
12. Warm up the engine for 5 minutes and check for any
engine oil leaks.
13. Once the engine is warm, switch it off and leave it to cool
for 10 minutes.
36
All manuals and user guides at all-guides.com
INSTRUCTIONS FOR USE
SW5500, FLOORTEC R 985 - 1466472000
DIESEL VERSION
Figure 26
C B A
P100927
03/2016
