Function menu
Freq
Period
Mean
Peak-Peak
Cyc RMS
Vmax
Vmin
Vtop
Vbase
Vamp
Overshoot
Preshoot
RiseTime
Fall Time
+Width
-Width
+Duty
-Duty
DelayA B
DelayA B
To measure the frequency of CH1 with Measurement 1 and the frequency of CH2 with Measurement 2, do
the following:
1. Press the MENU key and the function menu is shown at the right of the screen.
2. Press the MENU ▲ or MENU ▼ key to select Measurement 1. Five options appear at the bottom of the
screen.
Settings Description
CH1 Measure the frequency of CH1.
CH2 Measure the frequency of CH2.
CH1 Measure the period of CH1.
CH2 Measure the period of CH2.
CH1 Measure the average value of CH1.
CH2 Measure the average value of CH2.
CH1 Measure the peak-to-peak value of CH1.
CH2 Measure the peak-to-peak value of CH2.
CH1 Measure Root Mean Square (RMS) value of CH1.
CH2 Measure Root Mean Square (RMS) value of CH2.
CH1 Measure the Vmax of CH1
CH2 Measure the Vmax of CH2
CH1 Measure the Vmin of CH1
CH2 Measure the Vmin of CH2
CH1 Measure the Vtop of CH1
CH2 Measure the Vtop of CH2
CH1 Measure the Vbase of CH1
CH2 Measure the Vbase of CH2
CH1 Measure the Vamp of CH1
CH2 Measure the Vamp of CH2
CH1 Measure the Overshoot of CH1
CH2 Measure the Overshoot of CH2
CH1 Measure the Preshoot of CH1
CH2 Measure the Preshoot of CH2
CH1 Measure the RiseTime of CH1
CH2 Measure the RiseTime of CH2
CH1 Measure the Fall Time of CH1
CH2 Measure the Fall Time of CH2
CH1 Measure the +Width of CH1
CH2 Measure the +Width of CH2
CH1 Measure the -Width of CH1
CH2 Measure the -Width of CH2
CH1 Measure the +Duty of CH1
CH2 Measure the +Duty of CH2
CH1 Measure the -Duty of CH1
CH2 Measure the -Duty of CH2
CH1
Measure the DelayA
CH2
Measure the DelayA
CH1
Measure the DelayA
CH2
Measure the DelayA
B of CH1
B of CH2
B of CH1
B of CH2
