Classification No.
E051
E052
Electronics E070
errors
E071
E072
E073
E075
E076
E077
E078
E096
E097
E098
E121
E122
E124
Impermissi- E099
ble combina-
torics
Table 11: Error table
Additional explanations of error
codes
Installation and operating instructions Wilo-CronoLine-IL-E, CronoTwin-DL-E, CronoBloc-BL-E
Fault Cause
Impermissible DP/MP Different pumps
combination
DP/MP communica- Cable MP communication
tions time-out defective
Internal communica- Internal electronics error* Request customer service
tion error (SPI)
EEPROM error Internal electronics error
Power section/fre- Internal electronics error
quency converter
Impermissible elec- Internal electronics error
tronic module number
Charging relay Internal electronics error
defective
Internal transformer Internal electronics error
defective
24 V operating voltage Differential pressure sen-
for differential pres- sor defective or connected
sure sensor defective incorrectly
Impermissible motor Internal electronics error
number
Infobyte not set Internal electronics error
FlexPump data record Internal electronics error
missing
FlexPump data record Internal electronics error
invalid
Motor PTC short-cir- Internal electronics error
cuit
Interruption to NTC Internal electronics error
power element
Interruption to NTC Internal electronics error
electronic module
Pump type Different pump types have
been interconnected
*Error E006:
The inverters 11 – 22 kW do not check the connected power supply,
but instead the voltage drop in the intermediate circuit. Without load,
two connected phases are sufficient to charge the intermediate cir-
cuit. The error detection does not respond. It will only respond when
the pump is under load.
*Error E021:
Error "E021" indicates that the pump requires more power than is
permitted. To ensure that the motor and electronic module do not
suffer irreparable damage, the drive protects itself by switching the
pump off if an overload lasts more than 1 minute.
The most common causes of this error are a pump that is configured
too small, especially when pumping viscous fluids, or an excessive
volume flow in the system.
When this error code is displayed, there is not an error in the electronic
module.
Remedy
Request customer service
Check cable and cable
connections
Request customer service
Request customer service
Request customer service
Request customer service
Request customer service
Check differential pressure
sensor connection
Request customer service
Request customer service
Request customer service
Request customer service
Request customer service
Request customer service
Request customer service
Request customer service
English
Error type
HV AC
F F
E E
A A
A A
A A
A A
A A
A A
A A
A A
A A
A A
A A
A A
A A
A A
A A
