IEM Mobil-O-Graph Gebrauchsanweisung Seite 145

Guidelines and manufacturer's declaration – electromagnetic immunity
The Mobil-O-Graph ® is intended for use in the electromagnetic environment specified below. The customer
or Mobil-O-Graph ® user should ensure that it used only in such an environment.
Measurement of
interference emissions
Udstrålet RF-interferens
380 - 390 MHz
iht.
27 V/m; PM 50%; 18 Hz
IEC 61000-4-3
430 - 470 MHz
28 V/m; (FM ±5 kHz, 1 kHz Sinus)
PM; 18 Hz
704 - 787 MHz
9 V/m; PM 50%; 217 Hz
800 - 960 MHz
28 V/m; PM 50%; 18 Hz
1700 - 1990 MHz
28 V/m; PM 50%; 217 Hz
2400 - 2570 MHz
28 V/m; PM 50%; 217 Hz
5100 - 5800 MHz
9 V/m; PM 50%; 217 Hz
Test level
380 - 390 MHz
27 V/m; PM 50%; 18 H
430 - 470 MHz
28 V/m; (FM ±5 kHz, 1 kHz Sinus)
PM; 18 Hz
704 - 787 MHz
9 V/m; PM 50%; 217 Hz
800 - 960 MHz
28 V/m; PM 50%; 18 Hz
1700 - 1990 MHz
28 V/m; PM 50%; 217 Hz
2400 - 2570 MHz
28 V/m; PM 50%; 217 Hz
5100 - 5800 MHz
9 V/m; PM 50%; 217 Hz
Appendix
Compliance level
z
EN
71
