Adding Water During Operation; Using The Auto Start Function - Gastroback Design Tee Automat Advanced Plus Bedienungsanleitung

You start the WATER function via the WATER button. This function does not perform
any steeping cycle. You can set up the desired temperature before starting the func-
tion. When the set temperature is reached, the appliance switches to the keep warm
function at once (see: 'Properties of Your New Tea Maker / Keep Warm Function').
For avoiding high energy loss and surplus evaporation of water, the maximum tem-
perature of the keep warm function is limited to 90°C (194°F).
IMPORTANT - The keep warm function keeps running, even if the kettle has been
removed from the power base intermediately. You need to press the illuminated
start/stop button (in this case the WATER button) for cancelling the keep warm
function.
1. Without the filter system, prepare the appliance for operation (see: 'Preparing
the Appliance for Operation'). This means: the kettle is closed by the lid.
IMPORTANT - For operation, always correctly close the kettle via the lid. Other-
wise, the temperature control cannot operate correctly and high energy losses and
excessive evaporation occurs. Ensure that the lid set (lid ring and lid) is installed
firmly to avoid that the lid set falls during pouring.
WARNING
– The exterior of the kettle and lid set may get hot during ope-
ration! Only touch the kettle and lid by the handles. Boiling water, hot condensate
and steam may cause scalds and damage. Wait until the water stops boiling,
before pouring. Pour carefully to avoid spilling and beware of steam during pou-
ring. You should leave the lid set on the kettle during pouring.
IMPORTANT - Within the complete available temperature range of the appliance,
you can set up the desired temperature just before starting the WATER function.
However, before changing the temperature, ensure that none of the user-defined
programs are selected, because any changes to the settings of these programs
overwrite your former settings.
2. If the desired temperature is not shown on the display, press the TEMP/TIME button
and set up the correct temperature via the selection buttons + or –.
3. Press the WATER button to start the program. The WATER button illuminates.
During heating, a rising bar and the actual temperature within the kettle in steps
of 5°C (9°F) are shown. When the set temperature is reached, an acoustic
signal sounds and the appliance switches to the keep warm function immedia-
tely, with the KEEP WARM indicator illuminating.
4. By the handle, remove the kettle from the power base for pouring. Even without
the kettle, the keep warm function keeps running (see: 'Properties of Your New
Tea Maker / Keep Warm Function'). Before pouring, wait a moment until the
EN
98
water stops boiling. With the lid set closed firmly and correctly, it will not fall
during pouring.
5. If you wish to keep the water hot, ensure that there are still at least 250ml water
within the kettle (1cm or half an inch above the tip of the temperature sensor).
Then, place the kettle onto the power base again.
NOTE
Do not leave the water within the kettle uselessly to avoid excessive build-up of
lime within the kettle.

ADDING WATER DURING OPERATION

CAUTION
– Do not let cold water run down at the side walls of the
kettle, while the kettle is hot. When adding water during operation, always pour
the water slowly into the middle of the kettle. Otherwise, the glass body could
crack! Please observe the maximum filling level ("1.5L / MAX WATER"). If you
wish to use the keep warm function further on, although the filling level within the
kettle dropped below the minimum filling level of 250ml (approx. 1cm or half an
inch above the tip of the temperature probe), you need to add some water. The
water will be re-heated to the keep warm temperature automatically (max.
90°C/194°F; see: 'Properties of Your New Tea Maker / Keep Warm Function').
1. Remove the kettle from the power base and remove the lid from the lid ring.
2. Carefully and slowly pour the required amount of water into the middle of the
kettle, without letting cold water run down at the side walls of the kettle.
3. Re-place the lid in the lid ring and place the kettle onto the power base. The
kettle heats the water up to the keep warm temperature and carries on executing
the function as usual.

USING THE AUTO START FUNCTION

Via the auto start function you can set a point in time for starting the selected pro-
gram automatically. For this, prepare the appliance for operation and set the internal
clock of the appliance. Then, select the desired starting time. The appliance starts
the program, when the set starting time is reached.
IMPORTANT - Select the desired program first, and set up the required temperature
and steeping time, before activating the auto start function.
1. Prepare the filter system and the appliance for operation (see: 'Preparing the Fil-
ter System' and 'Preparing the Appliance for Operation').
EN
99
