7. Appendix

Th e following parts must be ob tained by the customer.
(Material: SUS303 or equivalent)
Installation nut
Tightening wrench
3.5
±0.2
(6) 8
Fastening wrench
5
±0.2
(6)
RU74 / RU77
2 × C0.5
4
±1
8
4 ø2.5 parallel pin press fitting or attachment
4 M3 (for securing ring)
Ring
4 × ø3 parallel pin press fitting or attachment
4 ø2.8
±0.1
Arm
Unit: mm
Unit: mm
Unit: mm
11
(E)
