General; Authorized Use - probst QUICKJET QJ-600-E Betriebsanleitung

General

3 General
3.1

Authorized use

The device (QJ-600-E) is exclusively applicable for lifting, transporting and laying of stone slabs, concrete
elements and also highly porous slabs and products with exposed aggregates and other rough surfaces, with
the corresponding suction plates.
This device can be hung from any carrier (e.g. excavator) by means of load hook, chains, cables and such like.
Various suction plates can be fitted to the device (QJ-600-E) via a quick release locating pin, enabling it to be
used for many different purposes and with many different loads.
The maximum permissible working load limit of the device of 600 kg must not be exceeded.
The lifting device is not suitable for suctioning loads with wet surfaces!
This device is equipped with the following safety devices:
•
With a fixed suction plate ESP 120-38/38 (working load limit/WLL max. 120 kg),
•
Electric power cable with on-off switch at the plug connector for external electricity supply
(230 V alternating current)
•
load securing chain.
Accessories:
•
Petrol-driven power generator SE-H Honda EU 22 i as alternative power supply to operate the unit
(QJ-600-E). Order No.: 52500243 (230V/ 50 Hz, 2.25 kW, weight 22.5 kg)
•
Adapter QJ for Speedy suction plates on QUIKJET QJ Order No.: 42420118
•
Adapter QJ for rotary head Bini/Baltrotor Order No.: 40110319
•
Wheel set QJ-RS for QUIKJET QJ Order No.: 42420083
•
Suction plate QJ-ESP 170-90/25 (WLL max. 170kg #) Order-No.: 42420110
•
Suction plate QJ-ESP 250-90/35 (WLL max. 250kg #) Order-No.: 42420112
•
Suction plate QJ-ESP 320-59/59 (WLL max. 320kg #) Order-No.: 42420102
•
Suction plate QJ-ESP 350-151/29 (WLL max. 350kg #) Order-No.: 42420108
•
Suction plate QJ-ESP 400-98/48 (WLL max. 400kg #) Order-No.: 42420104
•
Suction plate QJ-ESP 500-140/40 (WLL max. 500kg #) Order-No.: 42420114
•
Suction plate QJ-ESP 600-78.5/78.5 (WLL max. 600kg #) Order-No.: 42420106
#
value at -0,22 bar low pressure
To ensure proper function of the electric turbine when powering the QJ 600 e with a generator, be
aware of the following facts:
•
The minimum continuous power production has to be 1.600 W.
•
Exclusively power generators with modern inverter technology, such as a SE-H Honda EU 22 i , should
be used.
52400045 / 52400049 12 / 29 GB
