4.2.3 Service data
22 O P E R A T I N G I N S T R U C T I O N S | AHS/AHM36 IO-Link Basic
The following ISDUs are not backed up by data storage: device-specific marking and raw
position value.
IO-Link specific
Index deci‐ Name
mal (hex)
0 (0x00) Direct param‐
eter 1
1 (0x01) Direct param‐
eter 2
12 (0x0C) Device
Access Locks
2 Data Storage
Lock
(0x02)
16 (0x10) Vendor name String
17 (0x11) Vendor text
18 (0x12) Product
Name
19 (0x13) Product ID
20 (0x14) Product text
21 (0x15) Serial Num‐
ber
22 (0x16) Hardware Ver‐
sion
23 (0x17) Firmware ver‐
sion
24 (0x18) Application
Specific Tag
36 (0x24) Device Status UInt
40 (0x28) Process Data
Input
1 ro = read only, wo = write only, rw = read/write
SICK device specific
Index deci‐ Name
mal (hex)
13 (0x0D) Profile Char‐
acteristic
14 (0x0E) PDInputDe‐
scriptor
1 Position
(0x01)
Format Length Access 1
(Offset)
Record 16 bytes rw
Record 16 bytes rw
Record 2 bytes rw
Bit (1) 1 Bit rw
64 bytes ro
String 64 bytes ro
String 64 bytes ro
String 64 bytes ro
String 64 bytes ro
String 16 bytes ro
String 64 bytes ro
String 64 bytes ro
String 32 bytes rw
8 bits ro
PD in 8 bytes ro
Format Length Access
1
(Offset)
Array 8 bytes ro
Record 6 bytes ro
Bit (24) 3 bytes ro
Default Value Remark
value range [unit]
see IO-Link interface specification
see IO-Link interface specification
SICK AG
SICK Sensor Intelligence
AHx36x-xxxxxxxxxx
1xxxxxx
Absolute Encoder Multiturn
yywwnnnn
y = year
w = week
n = counter
1.0
1.1.0
Application-specific marking, writa‐
ble by user
0 = Device is OK
1 = Maintenance required
2 = Out of specification
3 = Functional check
4 = Failure
5 ... 255 = Reserved
As described in chapter see Process
Data, page 21, but acyclic
Default Value Remark
value range
[unit]
Unsigned see IO-Link interface
integer16 specification
[2]
see IO-Link interface specification
