4.2.2 Process Data
8022049/1EF3/2021-12-09 | SICK
Subject to change without notice
Record: 8 bytes
Byte offset
Byte 0 63
Velocity
Type/Subindex Integer 32
Byte offset
Byte 1 55
Velocity
Type/Subindex Integer 32
Byte offset
Byte 2 47
Velocity
Type/Subindex Integer 32
Byte offset
Byte 3 39
Velocity
Type/Subindex Integer 32
Byte offset
Byte 4 31
Position
Type/Subindex Unsigned integer 32
Byte offset
Byte 5 23
Position
Type/Subindex Unsigned integer 32
Byte offset
Byte 6 15
Position
Type/Subindex Unsigned integer 32
Byte offset
Byte 7 7
Position
Type/Subindex Unsigned integer 32
