Standard command
2 (0x02) Standard com‐
mand
1 ro = read only, wo = write only, rw = read/write
Error codes
Code decimal Additional code
(hex)
128 (0x80) 17 (0x11)
128 (0x80) 18 (0x12)
128 (0x80) 32 (0x20)
128 (0x80) 34 (0x22)
128 (0x80) 35 (0x23)
128 (0x80) 48 (0x30)
128 (0x80) 51 (0x33)
128 (0x80) 52 (0x34)
128 (0x80) 53 (0x35)
128 (0x80) 54 (0x36)
128 (0x80) 65 (0x41)
Position value for preset activation via pin 2
Bit Funktion
26 ... 1 Position value for preset activation via pin 2
NOTE
Evaluate the status flag A (index 92) at regular intervals to detect possible encoder
errors in a timely manner.
wo 128 Device Reset
130 Restore Factory Set‐
tings
Name
Index not available
Subindex not available
Service temporarily not
available
Service temporarily not
available - device control
Access denied
Parameter value out of
range
Parameter length overrun
Parameter length underrun Written parameter length is
Function temporarily not
available
Function temporarily not
available
Inconsistent parameter set Parameter inconsistencies
O P E R A T I N G I N S T R U C T I O N S | AHS/AHM36 IO-Link Basic
OPERATING INSTRUCTIONS
Requires device reset
Remark [unit]
Access to non-existent
index
Access to non-existent sub‐
index
Parameter is not accessi‐
ble due to the current state
of the device application
Parameter can be
accessed at the moment
because the device is cur‐
rently in remote operating
mode
Write access on a read-only
parameter
Written parameter value
is outside the permissible
value range
Written parameter length is
above its predefined length
below its predefined length
Written command is not
supported by the device
Written command is not
available due to the current
state of the device applica‐
tion
were found at the end of
block parameter transfer,
device plausibility check
failed
25
