3.2 Encoder with face mount flange
3.2.1 Mounting via threaded holes on the flange side (Fig. 3)
3.2.2 Mounting via the mounting spigot (Fig. 4)
3.3 Encoder with flange for blind hollow shaft (Fig. 5 and 6)
8022049/1EF3/2021-12-09 | SICK
Subject to change without notice
There are two mounting options for this type of flange:
Via the threaded holes on the flange side
■
By clamping on the mounting spigot
■
Mount coupling (1); ensure that it does not touch the encoder flange. Slide the encoder
(2) together with the mounted coupling (1) onto the drive shaft and the centering
fixture/mounting spigot. Mount the encoder (2) using three M3 screws (3) and mount
the coupling (1) on the drive shaft. The coupling must not be subjected to any axial
stress. Establish an electrical connection when the voltage is switched off. Switch on
the voltage and check that the encoder is functioning.
NOTICE
Since the mounting spigot is also a centering lug, the clamping device must be
designed so that no prohibited angles or shaft misalignments are made during the
clamping process.
Block the customer's drive shaft. Mount the coupling (1); ensure that it does not touch
the encoder flange when twisting the shaft. Slide the encoder (4) together with the
mounted coupling (1) onto the drive shaft and mounting spigot into the clamping device
(2). Clamp the encoder (4) with a screw (3). Mount the coupling (1) on the drive shaft.
The coupling must not be subjected to any axial stress. Establish an electrical connec‐
tion when the voltage is switched off. Switch on the voltage and check that the encoder
is functioning.
Block the customer's drive shaft. Loosen cylinder head screw (2) on the clamping ring
(1). Slide the encoder together with the collet onto the drive shaft. Take note of the
mounting information in Fig. 6! Mount the stator coupling (3) using two M3 screws (4)
and washers (5). Loosen cylinder head screw (2) on the clamping ring (1).
Tightening torque 0.75 to 0.8 Nm
Establish an electrical connection when the voltage is switched off. Switch on the
voltage and check that the encoder is functioning.
