Symbol Designation
[Down] button
Symbol Designation
[Confirm] button
4.3

Displays in the Operating Display

Symbol Designation
[Counting]
display
[Weighing in
percent] display
[Calculation]
display
[Animal weighing]
display
[Net-total] display
[Totalizing]
display
[Density
determination]
display
[Statistics] display
[Peak hold]
display
[Checkweighing]
display
[Busy] display
Description
— In the menu: Scrolls through the menu levels or the available parameters.
— When entering digits: Decreases the displayed value.
— In the main display of an application that is not active: Accesses the display to
set the reference values.
— In the main display of an active application: Switches to the display of the
current weight value | parameter.
Description
— In the menu: Accesses the displayed menu level or confirms the displayed
parameter.
— When entering digits: Selects the next digit position.
— In the main display of an application that is not active: Starts the application
process and saves the set reference value.
— In the main display of an active application: Adopts the next component or the
next parameter.
Description
Indicates that the "Counting" application is selected.
Indicates that the "Weighing in percent" application is selected.
Indicates that the "Calculation" application is selected.
Indicates that the "Animal weighing" application is selected.
Indicates that the "Net-total" application is selected.
Indicates that the "Totalizing" application is selected.
Indicates that the "Density determination" application is selected.
Indicates that the "Statistics" application is selected.
Indicates that the "Peak hold" application is selected.
Indicates that the "Checkweighing" application is selected.
Indicates that the device is processing a command.
