10.1 Cleaning
• Keep the equipment free of dirt and dust as far as
possible. Wipe the equipment with a clean cloth or
blow it down with compressed air at low pressure.
• We recommend that you clean the equipment im-
mediately after you use it.
• Clean the equipment regularly with a damp cloth
and some soft soap. Do not use cleaning agents
or solvents; these may be aggressive to the plastic
parts in the equipment. Ensure that no water can
get into the interior of the equipment.
• You must disconnect the hose and any spraying
tools from the compressor before cleaning. Do not
clean the compressor with water, solvents or the
like.
10.2 Maintenance work on the pressure vessel
(fig. 3)
m Important! To ensure a long service life of the
pressure vessel (2), drain off the condensed wa-
ter by opening the drain valve (1) each time after
using. Release the vessel pressure first (see 10.3.1).
Open the drain screw by turning counter-clockwise
(looking at the screw from the bottom of the com-
pressor) so that all the condensed water can run out
of the pressure vessel. Then close the drain screw
again (turn it clockwise). Check the pressure vessel
for signs of rust and damage each time before using.
Do not use the compressor with a damaged or rusty
pressure vessel. If you discover any damage, then
please contact the customer service workshop.
10.3 Storage
m Important!
Pull out the mains plug and ventilate the equip-
ment and all connected pneumatic tools. Switch
off the compressor and make sure that it is se-
cured in such a way that it cannot be started up
again by any unauthorised person.
m Important!
Store the compressor only in a dry location
which is not accessible to unauthorised persons.
Always store upright, never tilted!
10.3.1 Releasing excess pressure
Release the excess pressure by switching off the
compressor and using the compressed air which is
still left in the pressure vessel, e.g. with a compressed
air tool running in idle mode or with a blow-out pistol.
10.4 Safety valve (fig. 1, 7)
The safety valve (3) has been set for the highest per-
mitted pressure of the pressure vessel. It is not per-
mitted to adjust the safety valve or remove the con-
nection lock (3.2) between the exhaust nut (3.1) and
its cap (3.3).
22 | GB
Actuate the safety valve every 30 operating hours
but at least 3 times a year, to ensure that it works
when required. Turn the perforated exhaust nut (3.1)
counterclockwise to open it and use your hands to
pull the valve rod outwards over the perforated ex-
haust nut (3.1) to open the safety valve outlet. Now,
the valve audibly releases air. Then, tighten the ex-
haust nut clockwise again.
10.5 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be re-
placed by anyone but a qualified electrician.
10.6 Transport (fig. 1)
The compressor can be transported by tilting to the
wheels.
10.7 Ordering replacement parts
Please quote the following data when ordering re-
placement parts:
• Type of machine
• Article number of the machine
10.8 Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: Belt, clutch
* Not necessarily included in the scope of delivery!

11. Disposal and recycling

The unit is supplied in packaging to prevent
its being damaged in transit. This packaging
is raw material and can therefore be reused
or can be returned to the raw material sys-
tem. The unit and its accessories are made
of various types of material, such as metal
and plastic. Defective components must be disposed
of as special waste. Ask your dealer or your local
council.
