To change the distance of the packing wheels, carry out the
operations described.
1) Loosen the screws (B).
2) Move the packing wheel (A).
NOTICE
To open out the compactor wheel further, remove
screw (B) from hole (C) and screw into hole (D).
3) Repeat the same procedure to move the other pack-
ing wheel.
4) Tighten the screws (B).
Adjusting the packing wheel scraper
The scraper is used to clean the packing wheels, remov-
ing any soil and debris that has built up.
Proceed as outlined below.
1) Loosen the screw (A).
2) Turn the scraper (B) until it reaches the desired posi-
tion.
3) Tighten the screw (A).
4) Repeat the same procedure for the other scraper.
Adjusting the planting force (load applied to ground)
Use the ratchet lever (A) to increase or decrease the
weight on the packing wheels.
English language
ADJUSTMENT INFORMATION
To change the tilt of the packing wheels, carry out the op-
erations described.
1) Loosen the screws (E - F).
2) Tilt the packing wheel as needed.
3) Tighten the screws (E - F).
4) Repeat the same procedure to tilt the other packing
wheel.
UN41 0785NQ
UN41-0786NQ
17
B
A
Use and maintenance
5
A
