Instructions
• IEC 60335-2-40 applicable clauses Annex JJ and
Annex NN
15 - Warranty
Always transmit the model number and serial
number with any claim filed regarding this
product.
The product warranty may be invalied in
following cases:
• Absence of nameplate.
17 - Dual Pressure switch - Factory settings
Refrigerants
R404A/R507/R407A/R407F/R448A/R449A/R452A,R454C, R455A
R134a/R513A
18 - Dual Pressure switch - Refrigerant setting
Refrigerants
R134a, R513A, R1234yf
R404A/R507, R452A
R454C
R455A
R448A/R449A
19 - Fan speed controller setting
Fan speed Controller
FSC type
Spare part number
061H3144
061H3248
XGE-2C
* Installer can set the required setting based on application.
6 | AN37261865152501-010201 - 118A2176B
• External modifications; in particular, drilling,
welding, broken feet and shock marks.
• Compressor opened or returned unsealed.
• Rust, water or leak detection dye inside the
compressor.
• Use of a refrigerant or lubricant not approved by
Danfoss.
• Any deviation from recommended instructions
pertaining to installation,
maintenance.
High pressure settings (bar (g))
High pressure settings (bar (g))
Refrigerant
For Refrigerant
letter
S R134a/R513A
V R404A/R452A/R507
R404A/R507/ R407A/R407F/R448A/
X R449A/R452A (Except R134a and
R513A)
R404A / R507, R455A, R454C, R448A/
T
R449A, R452A
R404A / R507, R407A, R407F, R448A,
I R449A, R452A, R454C, R455A (Except
R134a and R513A)
• Use in mobile applications.
• Use in explosive atmospheric environment.
• No model number or serial number transmitted
with the warranty claim.
16 – Disposal
application or
ON OFF
23 27
13 17
ON OFF
14 17
24 27
19 23
21 25
22 26
Factory
setting
8 bar
15 bar
15 bar
15 bar
15 bar
Danfoss recommends that condensing
units and oil should be recycled by a
suitable company at its site.
Low pressure settings (bar (g))
ON OFF
2
2
Low pressure settings (bar (g))
ON OFF
2
2
2
2
2
Action required*
360°=1 turn = Approx 0.8 bar
(Clockwise rotation =
Increase pressure setting,
Counter clockwise rotation =
Decrease pressure setting)
Rotate the screw by 9 turns in counter
clockwise direction to reach 8 bar
© Danfoss | Climate Solutions | 2021.06
1
1
1
1
1
1
1
