Instruções
Dados técnicos (W09)
Modelo da unidade
Aplicação Códigos
de condensação
114X3204 OP-LSVM048NTW09G
114X3205 OP-LSVM048NTW09E
114X3206 OP-LSVM068NTW09G
114X3207 OP-LSVM068NTW09E
LBP
114X7295 OP-LSVM014DPW09G
114X7296 OP-LSVM016DPW09G
114X7297 OP-LSVM026DSW09G
114X7298 OP-LSVM034DSW09G
114X7274 OP-MSIM034MLW09E
114X7275 OP-MSIM034MLW09G
114X7276 OP-MSIM044MLW09E
114X7277 OP-MSIM044MLW09G
114X7278 OP-MSIM046MLW09E
114X7279 OP-MSIM046MLW09G
114X7280 OP-MSIM057MLW09E
114X7281 OP-MSIM057MLW09G
114X7286 OP-MSTM008DYW09G
114X7287 OP-MSTM009DYW09G
114X7288 OP-MSTM012DPW09G
114X7289 OP-MSTM014DPW09G
MBP
114X7290 OP-MSTM018DXW09G
114X7291 OP-MSSM012SCW09G
114X7292 OP-MSSM015SCW09G
114X7293 OP-MSSM018SCW09G
114X7294 OP-MSSM021SCW09G
114X7299 OP-MSTM022DSW09G
114X7300 OP-MSTM026DSW09G
114X7301 OP-MSTM026DSW09E
114X7302 OP-MSTM034DSW09G
114X7303 OP-MSTM034DSW09E
114X7304 OP-MSSM026CSW09G
114X7305 OP-MSSM030CSW09G
© Danfoss | Climate Solutions | 2021.06
Código
Refrigerante Compressor
Eléctrico
G V NTZ048-5
E V NTZ048-4
G V NTZ068-5
E V NTZ068-4
G V DPT14LA
G V DPT16LA
G V DST26NA
G V DST34LA
E I MLZ015T4
G I MLZ015T5
E I MLZ019T4
G I MLZ019T5
E I MLZ021T4
G I MLZ021T5
E I MLZ026T4
G I MLZ026T5
G T DLY80RAb
G T DLY90RAb
G T DPT12RA
G T DPT14RA
G T DX18TBa
G S SC12G
G S SC15G
G S SC18G
G S SC21G
G T DS22TB
G T DS26TB
E T DS26T3
G T DS34TB
E T DS34T3
G S CS26TB
G S CS30TB
Válvula
Chassis/
Recetor
de sucção
Comparti-
C
mento
Polegadas. Polegadas.
B2 3.4 5/8"
B2 3.4 5/8"
B2 3.4 5/8"
B2 3.4 5/8"
B1 1.3 3/8"
B1 1.3 3/8"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 1/2"
B1 1.3 1/2"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 3/8"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
118A2176B - AN37261865152501-010201 | 59
Válvula de Dimensões
líquidos da unidade (mm)
C Largura Altura
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
3/8" 364 910 530
3/8" 364 910 530
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
3/8" 364 910 530
3/8" 364 910 530
3/8" 364 910 530
3/8" 364 910 530
1/2" 364 910 530
1/2" 364 910 530
3/8" 364 910 530
3/8" 364 910 530
3/8" 364 910 530
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
1/2" 464 1079 690
