Illustration 2
Données techniques (W05)
Modèle du groupe
Application Codes
de condensation
114X7263 OP-LSVM014DPW05G
114X7242 OP-LSVM016DPW05G
114X7227 OP-LSVM026DSW05G
114X7228 OP-LSVM034DSW05G
LBP
114X7244 OP-LSVM048NTW05G
114X7245 OP-LSVM048NTW05E
114X7246 OP-LSVM068NTW05G
114X7247 OP-LSVM068NTW05E
114X7226 OP-MSTM008DYW05G
114X7229 OP-MSTM009DYW05G
114X7230 OP-MSTM012DPW05G
114X7231 OP-MSTM014DPW05G
114X7232 OP-MSTM018DXW05G
114X7238 OP-MSSM012SCW05G
114X7239 OP-MSSM015SCW05G
114X7240 OP-MSSM018SCW05G
114X7241 OP-MSSM021SCW05G
114X7233 OP-MSTM022DSW05G
114X7234 OP-MSTM026DSW05G
114X7235 OP-MSTM026DSW05E
MBP
114X7237 OP-MSTM034DSW05G
114X7236 OP-MSTM034DSW05E
114X7248 OP-MSSM026CSW05G
114X7249 OP-MSSM030CSW05G
114X7266 OP-MSIM034MLW05E
114X7267 OP-MSIM034MLW05G
114X7268 OP-MSIM044MLW05E
114X7269 OP-MSIM044MLW05G
114X7270 OP-MSIM046MLW05E
114X7271 OP-MSIM046MLW05G
114X7272 OP-MSIM057MLW05E
114X7273 OP-MSIM057MLW05G
© Danfoss | Climate Solutions | 2021.06
Illustration 3
Vanne Schrader
Boulons de montage (non fournis)
Code
Compres-
élec- Réfrigérant
seur
trique
G V DPT14LA
G V DPT16LA
G V DST26NA
G V DST34LA
G V NTZ048-5
E V NTZ048-4
G V NTZ068-5
E V NTZ068-4
G T DLY80RAb
G T DLY90RAb
G T DPT12RA
G T DPT14RA
G T DX18TBa
G S SC12G
G S SC15G
G S SC18G
G S SC21G
G T DS22TB
G T DS26TB
E T DS26T3
G T DS34TB
E T DS34T3
G S CS26TB
G S CS30TB
E I MLZ015T4
G I MLZ015T5
E I MLZ019T4
G I MLZ019T5
E I MLZ021T4
G I MLZ021T5
E I MLZ026T4
G I MLZ026T5
Dans le sens inverse des aiguilles
d'une montre (ouvert)
Dans le sens des aiguilles d'une
montre (fermé)
Vanne
d'aspi-
Châssis/ Réservoir
ration
Boîtier L
Pouce
B1 1.3 3/8"
B1 1.3 3/8"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 5/8"
B2 3.4 5/8"
B2 3.4 5/8"
B2 3.4 5/8"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 1/2"
B1 1.3 1/2"
B1 1.3 3/8"
B1 1.3 3/8"
B1 1.3 3/8"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 1/2"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
B2 3.4 3/4"
