17.2.2.1 Stationsparameter

Die Parameter der Station setzen allgemein den Profinet IO Knoten. Einige dieser Einstellungen
werden in den Modulen als Voreinstellung genutzt und können optional innerhalb der
Modulkonfiguration überschrieben werden.
Parameter
Temperature unit
Message diagnostics
Value behavior on module fault All process data are immediately reset
Bottom temperature of output 1 Set Bottom temperature of analog output 1
Top temperature of output 1
Bottom temperature of output 2 Set Bottom temperature of analog output 2
Top temperature of output 2
Source (head) for output 1
Source (type) for output 1
Analog output 1 mode
Source (head) for output 2
Source (type) for output 2
Analog output 2 mode
MI3
Description
Set the temperature unit
The diagnostics information of all modules are not
transferred to the Profinet I/O controller
transferred to the Profinet I/O controller
All process data maintain the last status
Set Top temperature of analog output 1
Set Top temperature of analog output 2
Set head number
Set type of source for output 1
Set output mode
Set head number
Set type of source for output 2
Set output mode
Rev. F2 03/2014
Ethernet
Setting
Celsius
Fahrenheit
message inactive
diagnostic alarm
set process data to zero
set process data to last value
0...3000°C /°F
0...3000°C /°F
0...3000°C /°F
0...3000°C /°F
1..8
Internal temperature
Object temperature
TCJ
TCK
TCR
TCS
0...5V
0...10V
tristate (disabled)
1..8
Internal temperature
Object temperature
0...20mA
4...20mA
0...5V
0...10V
tristate (disabled)
