4.3 X13 connection in ACU501 and ACU601
When an ACU501 or ACU601
X13
05/16
device is used, connection of AC 3x400 V at X13 is required.
1 ... 6
7
8
9
10
Connected load
Supply voltage
Supply frequency
Quick Start Guide ACU 201, ACU 401, ACU 501, ACU 601
Auxiliary voltage terminal X13
Not used
PE
L1
L2
L3
Connection
≥ 1.2 kW
400 V +- 10 %
50 / 60 Hz
