Type
ACU401
ACU501
160.0...400.0
ACU601
NOTE
Before unpacking the frequency inverter, transfer it as close as possible to the designated place of
installation.
•
•
•
54
ACU401 Size 8 (160 to 400 kW)
ACU501 Size 8 (160 to 400 kW)
ACU601 Size 8 (160 to 400 kW)
Dimensions in mm
a
kW
1067
First, remove the protective packaging.
Screw 2 crane eyebolts into the threads provided for that purpose.
Use the crane eyebolts and a crane for lifting, handling and installation. The crane must be of a
design that it can carry the weight of the frequency inverter.
Quick Start Guide ACU 201, ACU 401, ACU 501, ACU 601
The diameter of the fixing holes is 8.5 mm.
Screw the rear wall of the frequency inverter
heat sink to the mounting plate.
b c
439 375 1017
Assembly dimensions in mm
a1 b1 b2
330 110
c1
345
